High Quality 200kg Mini Digger with CE Hy380

Jinan Sinoheng Import and Export Co., Ltd.
  • Type：Universal Type
  • Transmission：Hydraulic Transmission
  • Walking Mode：Wheeled
  • Load and Unload Method：Front Discharge
  • Certification：CE
  • Condition：New

Base Info

  • Model NO.：HY380
  • Operating Load：200kg
  • Transport Package：Nude,Container
  • Specification：CE, ISO9001: 2000
  • Trademark：SINOHENG
  • Origin：China
  • Production Capacity：800PCS,Month

Description


ItemHY380With Chevron engineering TyreMetricU.SMax working height(H3)2134mm84.37 inchMax pin height(H2)1844mm74.17 inchMax dumping height(H1)1488mm58.58 inchMax Dumping distance(E)348mm13.7 inchMax Dumping Angel(α3)30º30ºRollback of bucket on ground(α2)25º25ºDeparture angel(α1)11º11ºTotal height(H)1233mm48.54 inchGround clearance(F)118mm4.65 inchWheel base(L1)636mm25.0 inchOverall length without bucket(L3)1752mm69.0 inchTotal width(B2)1160mm45.67 inchBucket width(B1)980mm38.6 inchTotal length with bucket(L)2206mm86.9 inchTurn radius forward turning(R)1307mm51.5 inchEngine  Rated Power(KW) Rotating speed(rpm) Noise(Db)≤95Hydraulic System Pressure(Mpa)17Working Time(s) Raise4.27Dump1.34Lower3.31Operating Load200Kg441LbBucket Capacity0.15m³5.33ft³Max Lifting Force375Kg827LbTravel Speed0-5.5Km/h0-3.4mile/hOperating Weight890kg1958lb
