• Model NO.：SWL4018
• Hydraulic Cylinder Brand：Kyb
• Power：41.7,2600kw,Rpm
• Warranty：2 Years
• Dimension(Long * Breadth * High)：3318X1600X2014
• Color：Blue
• Unique Selling Point：High Power Engine
• Applicable Industries：Advertising Company, Building Material Shops
• Bucket Capacity：0.4mm
• After-Sales Service Provided：Field Installation, Commissioning and Training
• Hydraulic Valve Brand：Kyb
• Hydraulic Pump Brand：Kyb
• Machine Weight：1600mm
• Moving Type：Wheel Loader
• Engine Brand：Isuzu
• Specification：3318X1600X2014
• Trademark：SUNWARD
• Origin：Hunan, China
• Production Capacity：100000 Set,Sets Per Year

Dimension(L×B×H)mm3686×2015×2098Working parametersAMaximum overall heightmm4108BHeight to hinge pinmm3210CHeight to top of cabmm2098DHeight to bottom of level bucketmm3034ELength without standard bucketmm2927FLength with sandard bucketmm3686GMaximum dump angle°43HDump heightmm2453JDump reachmm876KRolback angle (bucket on ground)°30LRolback angle at maximum height°92MWheelbasemm1233PGroundmm205QDeparture angle°28RTurning radius from center (Coupler)mm1365STurning radius from center (Bucket)mm2245TTurning radius from center (Machine rear)mm1751UBumper overhang behind rear axlemm1063VWidth over tiremm1501WBucket widthmm2015Operating weightkg4000PerformanceRated operating capacitykg1500Tipping loadkg3000Breakout force curlkg3450Breakout force liftkg3000Travel speed (Double speed)km/h10/20Bucket capacitym30.53EngineBrand KUBOTAModel V3800DI-TType 4-cylinder, water cooling, diesel engineEmission standard EPA Tier3 / EU Stage III APowerkW/rpm74/2600Maximum torqueN.m/rpm325/1600Electrical SystemStarting motorV/kW12/3.0GeneratorV/A12/80BatteryAh120Fueling AmountHydraulic oil tankL65Fuel tankL90Hydraulic SystemStandard dischargeL/min95Large dischargeL/min170Standard working pressurebar210Large-discharge working pressurebar165
