Sunward Swe155f Mini Amphibious Excavator Hydraulic Control Valve in Stock
Sunward Intelligent Equipment Co., Ltd.- Type：Crawler Excavator
- Usage：Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
- Bucket：Backhoe
- Transmission：Hydraulic Transmission
- Drive Type：Electric Drive
- Bucket Capacity：0.6mmm
Base Info
- Model NO.：SWE155F
- Size：7815X2600X2825 mm
- Certification：ISO9001
- Condition：New
- Warranty：2 Years
- Rated Speed：5.4,Km,H
- Hydraulictank：150L
- Maximum Digging Depth：5640mm
- Operatingweight：14.8t
- Operating Weight：15 Ton
- Moving Type：Crawler Excavator
- Maxdiggingheight：8630mm
- Power：84kw,2200rpm
- Maximum Digging Height：8630mm
- Applicable Industries：Manufacturing Plant
- Unique Selling Point：Low Fuel Consumption
- Wheelbase：3000mm
- Max Digging Radius：8355
- Local Service Location：Indonesia
- Specification：15 Ton
- Trademark：SUNWARD
- Origin：Hunan, China
- Production Capacity：100000 Set,Sets Per Year
Description
Size(L×W×H)7825×2600×2825 mm A)Wheel-base 3000mm B)Crawler length 3765mm C)Ground clearance of platform 940mm D)Tail slewing radius of platform 2355mm E)Width of upper body 2520mm F)Gauge 2000mm G)Chassis width 2600mm H)Track width 600mm I)Chassis ground clearance 410mm J)Cab roof height 2825mm K)Transport boom height 2600mm L)Transport length 7825mm a)Max.digging height 8700mm b)Max.dumping height 6200mm c)Max.digging depth 5525mm d)Max. vertical digging depth 5000mm e)Max.digging radius 8370mm f)Max.digging reach at ground level 8225mm h)Min.slewing radius 2645mm Operating weight(steel track) 15.6t Standard bucket capacity 0.61m3 Bucket digging force 100kN Bucket rod digging force 76kN Travel speed(Max./Min.) 5.3/3.2 km/h Ground pressure 36.8kPa Swing speed 11rpm Engine Brand Cummins Model QSF3.8 Type 4-cylinder, 4-stroke, water cooled, turbocharged Power 93kW/2200rpm Displacement 3.8L Fuel tank 245L Hydraulic tank 150L
Outline dimension
Operating range
Performance parameters
Oil tank capacity
