• Model NO.：SEM919
• Engine Brand：Weichai
• Rated Power/Speed：100,2200kw,Rpm
• Maximum Lift Above Ground：410mm
• Maximum Depth of Cutting：535mm
• Moldboard Width X Height：3710×610mm
• Travelling Speed ,Forward：42km,H
• Transport Package：Nude
• Specification：8015× 2380× 3050mm
• Trademark：Oriemac
• Origin：China
• HS Code：8429209000
• Production Capacity：100units Per Month

ItemsSE-M919Operation Weight (Base Machine)15,070kgOverall Dimensions (L*W*H)8,703*2,630*3,360mmBlade Length (L*W*H)3,974*25*607mmMax. Lifting Height475mmMax. Depth of Cut715mmMax. Drawbar≥78kNWheelbase6,140mmFrame Articulation Angle20°Min. Turning Radius7.8mEngine BrandSDEC SC9DK190.1G3Rated power140kWTransmission TypeHangchi 6WG180Travel Speed (Forward/Rear)40/25km/hRear Axle/TandemSE-M ST22Service brakeOutboard disc with brake caliper,Air to oil ControlOscillation (Front up/Rear up)15/25°Max. Oscillation Angle±16°Steering Angle (Left/Right)47.5°Max. Lean Angle of Front Wheels18°Hydraulic SystemLoad sensing,PPPC
