Cat 966 950f 950h Loader for Sale, Used Cat 966h Wheel Loader. Cat 966h 966f 966g 950f 950g
Shanghai Vostosun Industrial Co., Ltd.- Certification：ISO, CE
- Condition：New
- Rated Load：1-3t
- Transmission：Hydraulic
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
Base Info
- Model NO.：VSL50
- Type：Small Loader
- Rated Capacity (M3)：3m3
- Maximum Tractive Force：168kn
- Model of Engine：Weichai4rnsg3 ,Cummins 4bt3.9-C100
- Overall Weight：17000kg
- Max. Dump Height (mm)：3300
- Dump Distance(mm)：1300
- Specification：6130x1920x2820mm
- Origin：China
- HS Code：8429510000
- Production Capacity：50sets,Month
Description
Shanghai VOSTOSUN Industrial Co., Ltd was founded in 2006, it is a subsidiary company of AVP GROUP, which has been focusing on centralized procurement and supply services for engineering, mining and Civil or Construction Project over the past decade.Cooperating with excellent institutes in the domestic industries, domestic high-quality suppliers, international financial and insurance partners, we have integrated all high-quality resources and established a mature oversea regional service networks around the world, e.g, regional service centers in Russia, Kazakhstan and Australia, providing machinery, equipment and parts display, warehousing and after-sales services throughout the country. Our service covers more than 30 countries and regions including Eastern Europe, Central Asia, The Middle East, Africa, South America, Southeast Asia, and Australia,etc.
Since 2006, SHANGHAI VOSTOSUN, as the UN(United Nations) designated supplier for the procurement and supply of machinery & equipment for its aid projects in Asia and Africa, has provided lots of machineries, equipment and general contracting services for many national large-scale projects, such as:
·Kazakhstan Astana Capital Moving Project,
·Russia Voronezh Nuclear Power Station,
·Shanghai Pengxin Mining Congo (Gold) Copper Project,
·Equatorial Guinea National Highway Equipment General Contracting.
| rated load | 5000kg |
| overall weight | 17000kg |
| rated budet capacity | 3m |
| maximum tractive force | 168KN |
| maxinun breakout force | ≥173KN |
| maximum grade ability | 359C |
| maximum dump height | 3300mm |
| maximum dump Teach | 1300mm |
| overall dimension (LxWxH) | 8085*2963x3463mm |
| minimumn tuming radius | 6500mm |
| model | WD10G220E23 |
| type | lnline water cooling dry cylinder injetion |
| -xNo. of cyinder-bore/stoke | 6-126x130mm |
| ratedpower | 162w-2400r/mi |
| maximum torque | 860N.m |
| min fnel-consume ratio | s215g/kw.h |
| torque converter | ,,() Single stage. two-phase,four-element (dual-turbine) |
| geabox mode | |
| gear shit | 4,44 forward and 4 reverse gears |
| maximumn speed | 39lkm/h |
| : main reducing spiral | bervel gear grade 1reduction |
| decelerating mode | planetay reduction,grade1 |
| wheel base (mm) | 3200omm |
| wheel tread | 2200m |
| mininum ground clearance | 500mm |
| sytem working pesse | 16MPa |
| boom lifing time | 5.1s |
| total time | 9.3s |
| 29 fiuel tank capacity | 300L |
