• Model NO.：SR18M-2
• Compaction Depth：40cm
• Engine Type：Petrol Engine
• Travel Speed：F1: 2.1,F2: 4.1,F3: 8.8
• Certification：EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
• Condition：New
• Transport Package：Nude Packing
• Specification：18t
• Trademark：shantui
• Origin：China
• HS Code：8429401900
• Production Capacity：10000units,Month

Basic Info.

Model NO. SR18M-2 Compaction Depth 40cm Engine Type Petrol Engine Travel Speed F1: 2.1,F2: 4.1,F3: 8.8 Certification EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008 Condition New Transport Package Nude Packing Specification 18t Trademark shantui Origin China HS Code 8429401900 Production Capacity 10000units/Month

Product Description

                     Shantui 114kw/2000rpm Sr18m-2 Road Compact Hydraulic High Quality Road Roller
SINGLE DRUM TYPE SR18M-2OVERALL WEIGHT18000kgENGINE POWERWith 114kW/2000rpm , this engine conforms to China-II emission regulation.

Operating cost
The structural parts inherit the excellent quality of Shantui mature products to realize high durability.
The core electric and hydraulic parts adopt imported products, featuring stable and reliable quality and extremely high reliability.
This product is powered by Dongfeng Cummins 6BTA5.9-C180 turbocharged and intercooled engine, featuring excellent fuel economy, really high market ownership volume, strong parts universality, and low maintenance cost.

Parameter name	SR18M-2
Performance parameters
Operating weight (Kg)	18000
Exciting force (KN)	350/175
Vibration frequency (Hz)	30/30
Nominal amplitude (mm)	2.0/1.0
Ground pressure (KPa)	-
Gradeability (%)	30
Engine
Engine model	6BTA5.9-C155
Rated power/rated speed (kW/rpm)	114/2000
Overall dimensions
Overall dimensions of machine (mm)	5990*2370*3215
Driving performance
Forward speed (km/h)	F1: 2.1,F2: 4.1,F3: 8.8
Reversing speed (km/h)	R1:2.1,R2:4.1
Chassis System
Wheelbase (mm)	-
Tank capacity
Fuel tank (L)	295
Working device
Compacting width(mm)	2140
