Concrete Vibrator Shaft, Japanese Type with Clamp

Ningbo Ace Machinery Co., Ltd.
  • Type：Concrete Vibrator
  • Shotcrete Type：Wet
  • Machining Process：Assembly
  • Structure：Cylinder Type
  • Productivity：60m²,h
  • Feeding Height：1370mm

Base Info

  • Model NO.：ZX-45
  • Vibrating Amplitude：1.2mm
  • Certification：ISO9001: 2000, CE
  • Condition：New
  • Color：Color-Zinc
  • Product Name：Concrete Vibrator Shaft
  • Japanese Type：with Clamp
  • Dia of Head：45mm
  • Dia of Flexible Hose：32mm
  • Dia Fo Flexible Shaft：12mm
  • Weight：16kgs
  • Packing Size：75*75*5.5cm
  • Transport Package：Carton
  • Specification：45mm
  • Trademark：kzw
  • Origin：Ningbo, China
  • HS Code：84314990
  • Production Capacity：5000 PCS,Month

Description

Main Technical dateModel Interational typeDomestic typeZX-32ZX-38ZX-45ZX-60ZX-35ZX-50ZX-70Diameterφ (mm)32384560355070LengthL (mm)583580583577400479555Vibrating Frequency(HZ)220200200200200200200Vibrating Ampitude(mm)0.821.21.21.250.911.151.35Diameter of flexiable hoseD(mm)30303236303636Diameter of flexiable shaftD(mm)10101213101313Weiht with 6mtr hose(kg)14.51516231420.524packing sizecm75*75*5.5 mm
