Rotary Drilling Rig Xr150 with Cheaper Price
Acntruck Automobile Sales (Shanghai) Co., Ltd.- After-sales Service：Provide
- Warranty：1 Year
- Type：Drill
- Pressure Pile Driver Type：Hydraulic Pile Driver
- Pile Hammer Type：Diesel Hammer
- Power Source：Diesel
Base Info
- Model NO.：XR150
- Motor Power：373kw
- Noise：Without Noise
- Certification：CS, CE, ISO 9001:2000, ISO 9001:2008
- Condition：New
- Max. Pile Diameter(mm)：2800
- Max. Pile Depth(M)：93
- Overall Drilling Weight：120
- Transport Package：Nude Package
- Specification：20572*3900*3664mm
- Origin：China
- HS Code：8430691100
- Production Capacity：50000PCS,Year
Description
KELLY DRILLING Drilling Torque max. 400kN.m Diameter max. 2800mm Depth max. 94m KELLY BAR Friction kelly bars ¢530-5×20m ¢508-5×20m Mechanical inter-locking kelly bars ¢530-4×20m ¢508-4×20m ROTARY HEAD Max spin off speed(options) None Max drilling speed 6-32rpm MAST Mast raking forward 5° Mast side forward ±5° Mast raking backforward 15° UNDERCARRIAGE Crawlers Length 6700mm Crawlers Width 3900-5200mm ENGINE Model top QSX15 Rated power 373kw HYDRAULIC PUMPS Main pumps 35Mpa Auxiliary pumps 4Mpa MAIN WINCH 1st Layer nominal line pull 400kn 1st Layer nominal rope speed 64m/min Rope diameter 36mm SERVICE WINCH 1st Layer nominal line pull 103kN 1st Layer nominal rope speed 65m/min Rope diameter 20mm WINCH CROWD Crowd force(pull down/pull up) 400/400 kN Pull down stroke 17000 mm DIMENSION & WEIGHT Transport width 3900mm Transport height 3664mm Transport length 20572 mm Weight(with standard kelly bars) 120 ton Min working radius 5529mm
