• Model NO.：SQ2SK
• Trademark：YS
• Origin：China
• Production Capacity：1000 PCS

Basic Info.

Model NO. SQ2SK Trademark YS Origin China Production Capacity 1000 PCS

Product Description

SQ2SK truck crane is a kind of equipment to realize the lifting, turning and lifting of goods through the hydraulic lifting and telescopic system. It is usually assembled on the truck, and generally consists of the truck chassis, cargo compartment, force lifter and crane.
The work characteristics of lifting equipment is to do intermittent movement, that is, in a working cycle to take materials, migration, unloading and other actions of the corresponding mechanism is alternately work, crane in the market development and use more and more widely.
Due to no leg hoisting and lifting driving often appear some accidents, traffic also relatively crawler crane, crawler crane fast, stable operation, large lifting weight, can walk hoisting in certain scope, but must ensure that the road smooth solid, tire pressure conforms to the requirements, shall not exceed 50 cm off the ground, long walk with load is prohibited.
In order to ensure the safety of operation, we should pay attention to the surrounding conditions when using SQ2SK crane. The working radius of the crane is not allowed to be manned, and the crane should be operated strictly in accordance with the specifications.


Item	Unit	Data
Max lifting Capacity	KG	2100
Max lifting Moment	T.M	4.2
Recommend Power	KW	9
Oil Flow of Hydraulic System	L/min	20
Pressure of Hydraulic System	MPa	16
Oil Tank Capacity	L	25
Crane Weight	KG	950
Installation Space	mm	850
Rotation Angle	°	360



Working Radius(m)	Length of Arm/Max lifting load 3.3m	Length of Arm/Max lifting load 5.66m	Length of Arm/Max lifting load 7.99m
2.10	2100	1000	420
2.50	1800	960	420
3.00	1000	920	420
3.50		880	410
4.00		800	410
4.50		730	400
5.00		600	400
5.50		400	390
6.00			370
6.50			350
7.00			310
7.50			290
7.73			255
