Pneumatic Pile Driver, Drop Hammer Pile Drive
Ji Ning Hengwang Mining Machinery Co., Ltd.- Type：Pressure Pile Driver
- Pressure Pile Driver Type：Hydraulic Pile Driver
- Pile Hammer Type：Hydraulic Hammer
- Power Source：Diesel
- Motor Power：90kw
- Noise：Without Noise
Base Info
- Model NO.：double head
- Certification：ISO 9001:2000
- Condition：New
- Spiral Drilling Diameter：150-600mm
- Sporal Drilling Depth：3000mm
- Drilling Diameter：76-450mm
- Drilling Depth：0-200m
- MPa Working Pressure：0.7-1.6 Mdeium Pressure
- Drilling Pipe Diameter：76mm
- Machine Weight：6.5t
- Transport Package：20 Feetcontainer
- Specification：4.6*2.2*2.7m
- Trademark：HW
- Origin：China
- HS Code：8430100000
- Production Capacity：200
Description
Model
HWZGX-390L
Hammer Model
390
Rod Diameter /mm
0-400
Duplex gear pump pressure(mpa)
20
Duplex gear pump displacement(ml/r)
40
hydraulic system pressure(mpa)
20
Overall Machine weight /T
5.8
80
rotation angle /°
360
rotation semi diameter/mm
1925
Effective press pile stroke/mm
0-4000
dimension(LXWXH)(××)/mm
4650×2150×2700
track shoe(mm)
350
Walking motor total emissions (ml/n)
1575
Walking motor rated pressure (mpa)
18
walking motor output torque(n.m)
4300
walking motor rotation(r/min)
50
If you want to know more details.please contact me.
Molly: 0086 13563710733
