Lutong Road Roller Ltc214 Price Road Roller Lawn Roller on Sale
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Type:Road Roller
- Working Method:Steel Wheel
- Axle:Biaxial Three-Wheel
- Grinding Wheel Type:Light Grind
- Compaction Depth:40cm
- Engine Type:Diesel Engine
Base Info
- Model NO.:LTC214
- Travel Speed:40cm,s
- Centrifugal Force:40KN
- Certification:CS, ISO 9001:2000, ISO 9001:2008
- Condition:New
- Operating Mass:14000kg
- Front Axle Load:6000kg
- Rear Axle Load:7000kg
- Static Linera Load:333n,Cm
- Form of Frame:Fork Type Frame
- Fuel Tank Capcaticty:154L
- Transport Package:Seawothy Packing
- Specification:Standard size
- Trademark:Lutong
- Origin:China
- Production Capacity:50 Per Month
Description
Main Technical ParametersMODEL LTC212
LTC214 LTC210
LTC208 Operating mass kg 12000/14000 10000/8000 Font axle load kg 6000/7000 5000/4000 Rear axle load kg 6000/7000 5000/4000 Stactic linear load N/cm 286/333 238/231 Form of frame fork-type fork-type Crabwise movement distance mm 170 170 Water tank capacity L 2x600 2x400 Fuel tank capacity L 154 80 Hydraulic tank capacity L 65 65 Vibration fraquency mm High ampl 0.8 0.67 Low ampl 0.4 0.34 Vibration fraquency hz High ampl 40 45 Low ampl 46 50 Centrifugal force kN High ampl . 160x2 90x2 Low ampl . 90x2 69x2 Travel speed km/h 0-12 0-11.1 Turning radius mm 7000 6000 Grade ability % 40 40 Steering angle ° ±35 ±35 Drum diameter mm 1350 1150 Drum width mm 2100 1730 Drum rim thickness mm 20 16 Transverse swing angle of the vibrating wheel ° ±8 ±8 Type of water spray mm pressure pressure Wheel base mm 3717 3217 Overall length mm 5060 4558 Overall width mm 2250 1840 Overall hieght mm 3300 2674 Ground clearance mm 324 324 Diesel model CUMMINS
6BT5.9 CUMMINS
4BT3.9 Diesel power kW 110 75 Diesel speed r/min 2300 2400
LTC214
LTC208
6BT5.9
4BT3.9
