Lz-9 Large Size Diesel Engine Concrete Spraying Shotcrete Machine

Zhengzhou Lead Equipment Co., Ltd.
  • Type：Shotcrete
  • Shotcrete Type：Dry
  • Machining Process：Welded Molding Machine
  • Structure：Spiral Type
  • Productivity：9m3,H
  • Feeding Height：1.17m

Base Info

  • Model NO.：LZ-9D
  • Certification：ISO9001: 2000, CE, SGS
  • Condition：New
  • Color：Yellow
  • Product Name：Spraying Shotcrete Machine
  • Drive Type：Electric Motor Drive, Pneumatic Drive, Diesel Driv
  • Transport Package：Plastic Wrap, Plywood Case, Free-Fumigation
  • Specification：ISO, CE, SGS
  • Trademark：Leadcrete
  • Origin：China
  • HS Code：84743100
  • Production Capacity：5000 Sets,Year

Description

Diesel engine driveOutput Capacity6-9m 3 /hMax. Horizontal Conveying Distance200mSuitable Mix Ratio(Cement/Sand)≤1:4~5Max. Aggregate SizeDia.20 mmConveying Hose Inner DiameterDia.64 mmConveying Pressure0.2-0.4MPa(29-58PSI)Air Consumption10~12m 3 /min(357-430CFM)Material Charging Height1.1mRotor Speed7.5-11r/minDiesel Engine20hp,2200rpm, Radiator CoolingDiesel Engine StartingElectric startClutch Type in Diesel EngineAutomatic ClutchAir VibratorOR100,OliOverall Dimension(length×width×height)2.66×1.11×1.50mNet Weight950kg
