• Model NO.：Caterpillar 140g
• Certification：ISO9001: 2000
• Condition：Used
• Brand：Caterpillar
• Model：Cat140g
• Year：2008
• Original Place：Japan
• Loading：Shanghai Port
• Transport Package：in Bulk or in Container
• Specification：excellent
• Trademark：caterpillar
• Origin：USA
• HS Code：84290900
• Production Capacity：10units,Month

Basic Info.

Model NO. Caterpillar 140g Certification ISO9001: 2000 Condition Used Brand Caterpillar Model Cat140g Year 2008 Original Place Japan Loading Shanghai Port Transport Package in Bulk or in Container Specification excellent Trademark caterpillar Origin USA HS Code 84290900 Production Capacity 10units/Month

Product Description

Used caterpillar motor grader, CAT 140G1. Overall Length:8310 mm
2. Width Over Tires:2440 mm
3. Height to Top Cab:3360 mm
4. Wheelbase:5920 mm
5. Tandem Axle Wheelbase:1520 mm
6. Blade Base:2570 mm
Specification Engine  Make Caterpillar Model 3306 Net Power Gear 5-6 150 hp 111.9 kw Number of Cylinders 6 Max Power 150 hp 111.9 kw Displacement 638 cu in 10.5 L
 Operational Std Operation Weight - Total 27822.3 lb 12620 kg Fuel Capacity 75 gal 284 L Oil System Fluid Capacity 7.7 gal 29.3 L Cooling System Fluid Capacity 12.5 gal 47.3 L Hydrauilc System Fluid Capacity 18 gal 68 L Tire Size 14x24 10PR Operating Voltage 24 V Alternator Supplied Amperage 40 amps
 Transmission Type direct drive power shift Number of Gears - Forward 6 Number of Gears - Reverse 6 Max Speed - Forward 25.5 mph 41 km/h Max Speed - Reverse 25.5 mph 41 km/h
 Steering Articulation L/R 50 degrees Turning Radius 24 ft in 7.3 m Front Axle Wheel Lean 18 degrees Oscillation - Total 32 degrees Ground Clearance 2 ft in 610 mm
 Hydraulic System Pump Type closed-centre, constant-presure system w/ variable displacement piston pump Pump Flow 51 gal/min 193.1 L/min Relief Valve Pressure 2150 psi 14823.7 kPa
 Moldboard Moldboard Width 12 ft in 3660 mm Moldboard Height 24 in 610 mm Moldboard Thickness 0.87 in 22 mm Max Depth of Cut 17.2 in 438 mm Side Shift Left 26 in 660 mm Side Shift Right 26 in 660 mm
 Circle Diameter 60.2 in 1530 mm Rotation 360 degrees Shift Left 25.6 in 650 mm Shift Right 20.5 in 520 mm Max Reach Outside Tires - Left 77.2 in 1960 mm Max Reach Outside Tires - Right 72 in 1830 mm Max Lift Above Ground 18.3 in 464 mm
 Dimensions Height to Top of Cab 11 ft in 3360 mm Overall Length 27.3 ft in 8310 mm Width Over Tires 8 ft in 2440 mm Wheelbase 19.4 ft in 5920 mm Blade Base 8.4 ft in 2570 mm Tandem Axle Wheelbase 5 ft in 1520 mm
Other motor graders are in stock
KOMATSU: GD605R-1, GD605R-2, GD511-3, GD623
CATERPILLAR: 12G, 120G, 14G, 140, 140G, 120H, 140H
