Shantui 10000kg Srd10 Double Drum Hydraulic Road Roller for Sale
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Type：Road Roller
- Working Method：Vibration
- Axle：Biaxial Dual-Drum
- Grinding Wheel Type：Tire Grind
Base Info
- Model NO.：SRD10
- Compaction Depth：40cm
- Engine Type：Diesel Engine
- Travel Speed：0-6km,H
- Centrifugal Force：82,40
- Certification：CE, ISO 9001:2000
- Condition：New
- Operating Weight (Kg)：1000 Road Roller
- Exciting Force (Kn)：110,65
- Vibration Frequency (Hz)：40,46
- Ground Pressure (Kpa)：200-460
- Gradeability (%)：30
- Engine Model：Cumins 4bt3.9-C110
- Rated Power/Rated Speed (Kw/Rpm)：82kw,2400rpm
- Wheelbase (mm)：3300
- Fuel Tank (L)：150
- Compacting Width(mm)：1700
- Transport Package：Container,RO-RO
- Specification：4420*1900*2950 mm
- Trademark：SHANTUI
- Origin：China
- HS Code：8429401900
- Production Capacity：100units,Month
Description
Basic Info.
Model NO. SRD10 Compaction Depth 40cm Engine Type Diesel Engine Travel Speed 0-6km/H Centrifugal Force 82/40 Certification CE, ISO 9001:2000 Condition New Operating Weight (Kg) 1000 Road Roller Exciting Force (Kn) 110/65 Vibration Frequency (Hz) 40/46 Ground Pressure (Kpa) 200-460 Gradeability (%) 30 Engine Model Cumins 4bt3.9-C110 Rated Power/Rated Speed (Kw/Rpm) 82kw/2400rpm Wheelbase (mm) 3300 Fuel Tank (L) 150 Compacting Width(mm) 1700 Transport Package Container/RO-RO Specification 4420*1900*2950 mm Trademark SHANTUI Origin China HS Code 8429401900 Production Capacity 100units/MonthProduct Description
SHANTUI 10000kg Double Drum Hydraulic Road Roller for Sale
Product discription
Two big anticorrosive sprinkling cisterles connected design, large capacity, electric control pressure intermittent sprinkling water.
Equipped with cab, optional air-conditioning or anti-roll frame
The overall shape is beautiful with the streamline design, and the console have a good view.
PARAMETER
| Parameter name | SRD10 |
| Performance parameters | |
| Operating weight (Kg) | 10000 |
| Exciting force (KN) | 110/65 |
| Vibration frequency (Hz) | 40/46 |
| Nominal amplitude (mm) | 0.75/0.35 |
| Ground pressure (KPa) | - |
| Gradeability (%) | 30 |
| Engine | |
| Engine model | Cumins 4BT3.9-C110 |
| Rated power/rated speed (kW/rpm) | 82kw/2400rpm |
| Overall dimensions | |
| Overall dimensions of machine (mm) | 4420*1900*2950 |
| Driving performance | |
| Forward speed (km/h) | F1: 0-6, F2: 0-12 |
| Reversing speed (km/h) | R1: 0-6, R2: 0-12 |
| Chassis System | |
| Wheelbase (mm) | 3300 |
| Tank capacity | |
| Fuel tank (L) | 150 |
| Working device | |
| Compacting width(mm) | 1700 |
