Inquiry About Mini Tractor Price with Front End Backhoe Loader From Manufacturer
Taian Zhengtai Construction Machinery Co., Ltd.- Certification：ISO
- Condition：New
- Rated Load：1-3t
- Transmission：Hydraulic - Mechanical
- Walking Mode：Wheeled
- Type：Small Loader
Base Info
- Model NO.：ZTW30-25
- Model：Ztw30-25
- Engine：Cummins 75kw, Xinchai 60kw
- Operating Weight：7660kg
- Backhoe Bucket Capacity：0.3cbm
- Rated Loading Bucket Capacity：1cbm
- Max Dump Heigh：2612mm
- Dump Reach at Max Dump Heigh：727mm
- Max.Digging Radius：5150mm
- Max.Dump Height：3738mm
- Radius at The Max.Dump Height：1084mm
- Max.Digging Radius at Ground Level：5105mm
- Digging Buckets Max.Rotating Angle：180
- Max.Digging Depth：4340mm
- Max.Digging Force：>50kn
- Min.Turning Radius：3795mm
- Transport Package：Nude
- Specification：7077*2350*3420mm
- Trademark：ZTMACHINE
- Origin：China
- HS Code：842959000
- Production Capacity：30
Description
VoltageV 12
2. spare parts or wearing parts will be packed in wooden box or paper carton. 3. Standard shipping method is by container.
Production description:
What is the main feature for backhoe loader ZTW30-25
1.7660kgs, CUMMINS engine, 4x4WD, Hydraulic torque converter transmission, Spacious cab, 0.3m3 bucket, 1m3 loading bucket, 7077*2350*3420mm
2.Low fuel consumption, low noise and strong power characteristics by using CUMMINS ENGINE (75kw)/XINCHAI ENGINE (60KW).
3.Super cab is designed with principle of ergonomics to provide the operator a low-noise environment, and possesses fine shock absorption.
4.Working table:water temperature, oil temperature, current, are all in sight.
5.Adjustable seat, convenient and comfortable to use.
6.Completely have the all functions of mini type digging machines.
7.Ascendant performance of complete appliance, with extraordinary operation efficiency.
Packing & Delivery
Container 40HC 2 units can be installed
1.Standard packing, the machine body is without packing, but the machine will be well fastened and fixed in the container by wire rope.
2. spare parts or wearing parts will be packed in wooden box or paper carton. 3. Standard shipping method is by container.
