Construction Equipment Shantui Super Large Horsepower Bulldozer SD90-C5
Acntruck Automobile Sales (Shanghai) Co., Ltd.- Type：Universal Type
- Transmission：Hydraulic Transmission
- Walking Mode：Crawler
- Load and Unload Method：Front Discharge
- Engine Power：708kw
- Certification：ISO9001: 2000
Base Info
- Model NO.：SD90-C5
- Condition：New
- Color：Yellow
- Operating Weight (Kg)：106260kg
- Ground Pressure (Kpa)：143.7
- Engine Model：Qst30
- Center Distance of Track (mm)：2770
- Width of Track Shoes (mm)：710
- Ground Length(mm)：4520
- Fuel Tank (L)：1638
- Blade Type：Semi-U Blade
- Digging Depth (mm)：1010
- Ripper Type：Single-Shank
- Ripping Depth (mm)：1670
- Specification：11500*5265*4590
- HS Code：8429521200
- Production Capacity：1000,PCS
Description
Basic Info.
Model NO. SD90-C5 Condition New Color Yellow Operating Weight (Kg) 106260kg Ground Pressure (Kpa) 143.7 Engine Model Qst30 Center Distance of Track (mm) 2770 Width of Track Shoes (mm) 710 Ground Length(mm) 4520 Fuel Tank (L) 1638 Blade Type Semi-U Blade Digging Depth (mm) 1010 Ripper Type Single-Shank Ripping Depth (mm) 1670 Specification 11500*5265*4590 HS Code 8429521200 Production Capacity 1000/PCSProduct Description
Construction Equipment Shantui Super Large Horsepower Bulldozer SD90-C5Features:
SD90-C5 crawler bulldozer is a high-efficiency high-power earth-moving machine designed and developed in response to the market demands, which achieved multiple technologic breakthroughs in terms of overall matching, thermal management system, and modular design.
This product is applicable for the earthworks for large projects such as mines and water conservancy projects.
This equipment can adapt to more severe working environment and fulfill the works that can't be substituted by other middle-sized and small-sized equipment and is an essential mechanical equipment for the construction of mines and water conservancy projects.
| Parameter name | SD90-C5 RS (Rock version) |
| Performance parameters | |
| Operating weight (Kg) | 106260 |
| Ground pressure (kPa) | 143.7 |
| Engine | |
| Engine model | QST30 |
| Rated power/rated speed (kW/rpm) | 708/2100 |
| Overall dimensions | |
| Overall dimensions of machine (mm) | 11500*5265*4590 |
| Driving performance | |
| Forward speed (km/h) | F1:0-3.5 F2:0-6.3 F3:0-10.9 |
| Reversing speed (km/h) | F1:0-4.7 F2:0-8.4 F3:0-14.3 |
| Chassis System | |
| Center distance of track (mm) | 2770 |
| Width of track shoes (mm) | 710 |
| Ground length(mm) | 4520 |
| Tank capacity | |
| Fuel tank (L) | 1638 |
| Working device | |
| Blade type | Semi-U blade |
| Digging depth (mm) | 1010 |
| Ripper type | Single-shank |
| Ripping depth (mm) | 1670 |
