• Model NO.：SD32-C5
• Engine Power：257kw
• Certification：CE, ISO9001: 2000
• Condition：New
• Color：Yellow
• Ground Pressure (Kpa)：92.7
• Engine Model：Qsnt-C345
• Rated Power/Rated Speed (Kw/Rpm)：257,1900
• Overall Dimensions of Machine (mm)：8545*3955*3624
• Forward Speed (Km/H)：F1:0-3.7 F2:0-6.7 F3:0-11
• Reversing Speed (Km/H)：R1:0-5 R2:0-8.2 R3:0-13.9
• Center Distance of Track (mm)：2100
• Width of Track Shoes (mm)：560
• Ground Length(mm)：Ground Length(mm)
• Blade Type：Semi-U Blade
• Digging Depth (mm)：589
• Ripper Type：Single-Shank,Three-Shank Ripper
• Transport Package：Nude Package,RO-RO,Bulk Shipment,Suitable Containe
• Specification：8545*3955*3624
• Trademark：shantui
• Origin：China
• Production Capacity：300piece,Month

Basic Info.

Model NO. SD32-C5 Engine Power 257kw Certification CE, ISO9001: 2000 Condition New Color Yellow Ground Pressure (Kpa) 92.7 Engine Model Qsnt-C345 Rated Power/Rated Speed (Kw/Rpm) 257/1900 Overall Dimensions of Machine (mm) 8545*3955*3624 Forward Speed (Km/H) F1:0-3.7 F2:0-6.7 F3:0-11 Reversing Speed (Km/H) R1:0-5 R2:0-8.2 R3:0-13.9 Center Distance of Track (mm) 2100 Width of Track Shoes (mm) 560 Ground Length(mm) Ground Length(mm) Blade Type Semi-U Blade Digging Depth (mm) 589 Ripper Type Single-Shank/Three-Shank Ripper Transport Package Nude Package/RO-RO/Bulk Shipment/Suitable Containe Specification 8545*3955*3624 Trademark shantui Origin China Production Capacity 300piece/Month

Product Description

2021 Shantui New Bulldozer SD32-C5 With Spare Parts In Stock



Product Description:The long life design ensures high firmness and durability.

Boat type frame of high carrying capacity: The boat type frame structure and the cast and welded rear axle feature high carrying capacity, high resistance against impact and bending moment, less welding, high strength, high reliability, and safer internal parts.

New track roller frame and final drive of higher durability: The planetary final drive features small volume, high carrying capacity, and high plane installation strength. The integral track roller frame features high durability, high resistance against mud accumulation and traveling wear, and long life.

Double drive shock-absorbing structure of higher durability: The newly added shock absorber assembly absorbs the impact load to protect the drive system. The drive assembly installation adopts semi-suspension elastic shock absorber to isolate the transmission of impact and double the comprehensive life.

Wearing parts of higher wear resistance: The wheel train are made of high-strength wear-resistant materials, with the overall quenched wearing layer thickness 2 times of that of domestic competing products and the cutting edges and end bits thicker by >20% than those of domestic competing products.

The modular design guarantees high availability.

More efficient replacement of modules: The drive module, traveling module, and power module can be disassembled/assembled and replaced independently without mutual influence or reliance on frame to realize the returned repair or independent replacement of module assembly and shorten the module replacement time by >2/3.

Better optimized match performance of modules: The match of power module and drive module is optimized to achieve high operating efficiency and quick acceleration response and increase the reversing speed by >7%.

Better comfortable and accurate single joystick control: The control system is upgraded to single joystick mode to achieve more accurate control, high sensitivity and labor-saving, and quick response.

More powerful floating traveling system: In the floating traveling system, the track rollers always keep contact with the chain tracks to increase the ground area of tracks and improve the traction force under complicated rough roads. The cylinders feature more uniform and reasonable force application and longer life and the blade features higher soil penetrating force.

Low-consumption power management

More efficient full-power match: Relying on the drive R&D and supply capability for the whole industry, the full-power match system in consideration of both power performance and fuel economy is developed independently to ensure excellent fuel economy under high load rate (75%-90%) conditions.

High-efficiency combustion and low fuel-consumption: By means of the combustion optimization, the engine CELECT electronic injection control technology matches with advanced double-pulse fuel injection cams and optimized piston and piston ring subassemblies to realize high-efficiency fuel injection and accurate and stable control, reduce the fuel consumption, and meet the Euro-IIIA emission regulation.

Low-consumption temperature control system: The fan speed is intelligently controlled to reduce the power loss and, while guaranteeing the optimal working temperature of cooling system, realize minimized power consumption.

Simple design and low maintenances

Less maintenance points: As the grease filling points are less for type K blade, the lubrication is not required for pulley of temperature controlled fan, and the wet type brake contains no brake band and is adjustment-free, the quantity of the lubricating points is reduced by 5~8 for the machine.

Less repair man-hours: The drive system splines are directly connected to save the adjustments, the chassis is upgraded to pivoted suspension to achieve simpler installation, the press-fit by large press is not required for the final drive, and the spline connections require no professional adjustment so that the overall repair man-hours are reduced.

Less malfunctions with built-in oil-ways: The drive system adopts built-in oil-way design to reduce the quantities of pipeline and harness connectors, parts, and malfunction points. The inclined oil pipes of the working hydraulic system are incorporated within the push rods for easy protection and less malfunctions.

More environmental-friendly cleaning operation: The sealed design of modules eliminates the oil leakage and realizes clean operations.

PARAMETER

Parameter name	Standard version
Performance parameters
Operating weight (Kg)	38500
Ground pressure (kPa)	92.7
Engine
Engine model	QSNT-C345
Rated power/rated speed (kW/rpm)	257/1900
Overall dimensions
Overall dimensions of machine (mm)	8545*3955*3624
Driving performance
Forward speed (km/h)	F1:0-3.7 F2:0-6.7 F3:0-11
Reversing speed (km/h)	R1:0-5 R2:0-8.2 R3:0-13.9
Chassis System
Center distance of track (mm)	2100
Width of track shoes (mm)	560
Ground length(mm)	3210
Tank capacity
Fuel tank (L)	587
Working device
Blade type	Semi-U blade
Digging depth (mm)	589
Ripper type	Single-shank/three-shank ripper
Ripping depth (mm)	Maximum 1,376 (Single-shank)/871 (Three-shank)
