• Model NO.：SD13
• Engine Power：74~147kw
• Certification：CE, ISO9001: 2000
• Condition：New
• Color：Yellow
• Operating Weight (Kg)：13700
• Ground Pressure (Kpa)：Ground Pressure (Kpa)
• Center Distance of Track (mm)：1880
• Width of Track Shoes (mm)：460
• Ground Lengthmm：2365
• Fuel Tank (L)：300
• Digging Depth (mm)：590
• Ripping Depth (mm)：567
• Transport Package：Nude Package,RO-RO,Bulk Shipment,Suitable Containe
• Specification：4492*3185*2950
• Trademark：shantui
• Origin：China
• Production Capacity：300piece,Month

Basic Info.

Model NO. SD13 Engine Power 74~147kw Certification CE, ISO9001: 2000 Condition New Color Yellow Operating Weight (Kg) 13700 Ground Pressure (Kpa) Ground Pressure (Kpa) Center Distance of Track (mm) 1880 Width of Track Shoes (mm) 460 Ground Lengthmm 2365 Fuel Tank (L) 300 Digging Depth (mm) 590 Ripping Depth (mm) 567 Transport Package Nude Package/RO-RO/Bulk Shipment/Suitable Containe Specification 4492*3185*2950 Trademark shantui Origin China Production Capacity 300piece/Month

Product Description

Shantui Bulldozer SD13 With 105kW/1900rpm Engine Power In Stock


Product Description:
Power System

Strong power, high efficiency and energy-saving, and low maintenance cost.

The rated power reaches 105kW, featuring high torque reserve coefficient.

The improved air filter and intake and exhaust system guarantee up to 99% filtration accuracy to effectively prolong the engine life.

Drive system

The curves of drive system and engine are perfectly matched to achieve more extensive high-efficiency zone and higher transmission efficiency.

Shantui's self-made drive system features stable performance and reliable quality and has been long proved by the market.

Driving/Riding Environment

The hexahedral cab provides super-large interior space and broad vision and the ROPS/FOPS can be installed depending on specific needs to ensure high safety and reliability.

The electronic control hand and foot accelerators guarantee more accurate and comfortable operations.

The intelligent display and control terminal and the A/C and heating system are installed to provide more abundant personalized driving/riding experience and enable you to understand system status at any time, featuring high intelligence and convenience.
Working adaptability

Shantui's mature product chassis system is applicable to diversified severe working conditions, featuring high stability and reliability.

The product features long ground length, high ground clearance, stable driving, and good trafficability.

The environmental sanitation blade, ripper, and universal blade can be installed depending on specific working condition to achieve strong working adaptability. The optional LED working lamps improve the illumination capability during nighttime operations to achieve higher safety and reliability.

Easy maintenances

The structural parts inherit the excellent quality of Shantui's mature products;

The electric harnesses adopt corrugated pipes for protection and deconcentrators for branching, featuring high protection grade.

The fuel filter element and the air filter are designed on one same side to achieve one-stop maintenances.

PARAMETER

Parameter name	SD13 (Standard version)	SD13S (Wetland version)	SD13R (Environmental sanitation version)	SD13C (Coal version)
Performance parameters
Operating weight (Kg)	13700	14900	15200	13900
Ground pressure (kPa)	53.8	38.4	39.2	54.6
Engine
Engine model	SC8D143G2B1(China-II)/SC8DK(China-III)	SC8D143G2B1(China-II)/SC8DK(China-III)	SC8D143G2B1(China-II)/SC8DK(China-III)	SC8D143G2B1(China-II)/SC8DK(China-III)
Rated power/rated speed (kW/rpm)	105/1900	105/1900	105/1900	105/1900
Overall dimensions
Overall dimensions of machine (mm)	4492*3185*2950	4492*3510*3000	4492*3510*3000	4492*3700*2950
Driving performance
Forward speed (km/h)	F1:0-3.2 F2:0-5.9 F3:0-9.8	F1:0-3.2 F2:0-5.9 F3:0-9.8	F1:0-3.2 F2:0-5.9 F3:0-9.8	F1:0-3.2 F2:0-5.9 F3:0-9.8
Reversing speed (km/h)	R1:0-3.9 R2:0-7.1 R3:0-11.9	R1:0-3.9 R2:0-7.1 R3:0-11.9	R1:0-3.9 R2:0-7.1 R3:0-11.9	R1:0-3.9 R2:0-7.1 R3:0-11.9
Chassis System
Center distance of track (mm)	1880	1880	1880	1880
Width of track shoes (mm)	460	700	700	560
Ground length(mm)	2365	2365	2365	2365
Tank capacity
Fuel tank (L)	300	300	300	300
Working device
Blade type	Straight tilting blade	Straight tilting blade	Sanitation blade	Coal blade
Digging depth (mm)	590	590	590	590
Ripper type	Three-shank	--	--	--
Ripping depth (mm)	567	--	--	--
