XCMG 12 Ton Xd123 China Double Drum Vibratory Compactor Machine New Road Roller Price for Sale
XCMG E-Commerce Inc.- Type：Double Drum Roller
- Working Method：Vibration
- Engine Type：Diesel Engine
- Travel Speed：0-12km,H
- Certification：EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
- Condition：New
Base Info
- Model NO.：XD123
- Weight：12300kg
- Grade Ability：35%
- Engine Brand：Cummins
- Power(W)：119kw
- Front Wheel Distribution Weight：6150kg
- Nominal Amplitude：0.3,0.75mm
- Exciting Force：85kn
- Vibration Frequency：55,45Hz
- Minimum Turning Radius (in/out)：4800,6930mm
- Specification：5146*2298*3096mm
- Trademark：XCMG
- Origin：Jiangsu, China
- HS Code：84294019
- Production Capacity：1000 Unit,Units Per Year
Description
Overview
Product ParametersParameter Unit XD123 Weight distribution Working weight kg 12300 Front wheel distribution weight 6150 Rear wheel distribution weight 6150 Maneuverability Speed range km/h I 0-6 / II 0-12 Theoretical gradeability % 35 Minimum turning radius mm (in/out) 4800/6930 Largest amount of crab mm ±160 Swing angle ° ±8 Steering angle ° ±35 Compaction performance Static linear load N/cm 283/283 Nominal amplitude mm 0.3/0.75 Vibration frequency Hz 55/45 Exciting force (high frequency/low frequency) kN 85/140 Engine Type Cummins rated power kw 98 rated speed r/min 2300
