• Model NO.：TS100
• Bucket Capacity(M3)：0.55
• Operating Load(Kg)：1200
• Dumping Height(mm)：2450
• Dumping Reach(mm)：700
• Wheelbase(mm)：1500
• Bucket Width(mm)：2030
• Usage：Special Type
• Load and Unload Method：Front Discharge
• Transport Package：Container
• Specification：ISO9001: 2000
• Trademark：SINOHENG
• Origin：China
• Production Capacity：200PCS,Month

Model
Main technical parameterTS100AOverall operating height(mm)4070BHeight to bucket hinge pin(mm)3150CHeight to top of cab(mm)2160DHeight to bottom of level bucket(mm)2983EOverall length without bucket(mm)3000FOverall length with bucket(mm)3700GDumping angle at maximum height(°)40HDumping height(mm)2450IDumping reach(mm)700JRollback of bucket on ground(°)30KRollback of bucket at full height(°)104LWheelbase(mm)1500MGround clearance(mm)200NAngle of departure(°)20OFront turning radius without bucket(mm)1365PFront turning radius(mm)2200QRear turning radius(mm)1742RRear axle to bumper(mm)938STread width, centerline to centerline(mm) 1654TWidth(mm)1994UBucket width(mm)2030

Model	TS100
Engine model	226B
Bore x stroke(mm)	106×130
Rated power (Kw)	70
Rotating speed(rpm)	2200
Number of cylinders	4
Max. torque (N.m)	380
Displacement  (L)	4.5
Max. Speed  (km/h)	12/18
Tire(track)  modei	320×84
Operating load(kg)	1200
Lifting	Arc lifting
Bucket capacity(m3)	0.55
Rated flux(L/min)	88
High Flow Flux(L/min)	122
Fuel tank capacity(L)	90
Self weight bucket(kg)	4280
