• Bucket Capacity：1.3m3
• Backhoe Capacity：0.3m3
• Max. Digging Depth：4082mm
• Loading Lifting Capacity：2500kg
• Transport Package：Bulk Vessel
• Specification：7600x2100x3100MM
• Trademark：Dongfeng
• Origin：China
• HS Code：8429590000
• Production Capacity：500 Units Per Month

Basic Info.

Bucket Capacity 1.3m3 Backhoe Capacity 0.3m3 Max. Digging Depth 4082mm Loading Lifting Capacity 2500kg Transport Package Bulk Vessel Specification 7600x2100x3100MM Trademark Dongfeng Origin China HS Code 8429590000 Production Capacity 500 Units Per Month

Product Description

Overall Operating Weight 6600KG Transport Dimension Dimension L*W*H 7600×2100×3100 Wheel base 2250mm Min. Ground Clearance 300mm Bucket Capacity 1.3m3 Breakout Force 38KN Loading Lifting Capacity 2500KG Bucket Dumping Height 3500mm Bucket Dumping Distance 1022mm Digging Depth 52mm Backhoe Capacity(Width) 0.3m3(520mm) Max. Digging Depth 4082mm Swing Angle of backhoe 190o Max. Pulling Force 39KN Engine Model YUNNEI 4102 Turbo Type In Line,Direct injection,Four-Stroke,Water Cooling Rated Power 76KW Rated Speed 2400r/min Displacement 4.4L Steering System Steering Angle ±36 o Min. turning radius 5018mm Pressure of the system 12Mpa Axle Model Wheel Hub Reducer Final Reducer Single Stage Final Reducer Transmission System Torque Converter Model YJ280 Type Single-stage Three Elements Cooling Method Oil-cooling Pressure Circulation Gearbox Type Power Transmission Gears Two Forward Gear, Two Backward Gear Max.Speed 28Km/h Optional Gears Four Forward Gear, Four Backward GearMax.Speed 40Km/h Tyre Model 16/70-20 Pressure of Front wheel 0.22 Mpa Pressure of Back Wheel 0.22 Mpa Brake System Service Brake Air Over Oil Caliper Brake External Type Self-regulation Self-balance Emergency Brake Operation Power Implementing brake Manual Operation Power Terminating Brake Hydraulic System Pressure of Hydraulic System 22Mpa Standard Configurations Front shovel with bucket, rear dig with bucket, luxury cab with interior trim, heater, fan, luxury adjustable swivel seat, adjustable instrument panel, front shovel and back dig are all hydraulic pilot operations, cab with push-pull Window, cab can be turned forward (easy for maintenance), 76KW Yunnei engine , 16/70-20 tires, 280 gearbox, double pump, enlarged wheel side bridge, A-shaped outrigger with lock, back digging swing belt Buffer function. The parameters or configuration are subject to change without notice.
