• Model NO.：63X-6RZ
• Automatic Grade：Automatic
• Product Capacity：40～400t,h
• Certification：CE
• Condition：New
• Boom Structure：63X-6rz
• Transport Package：Roro
• Specification：15530*4000*2800mm
• Trademark：SINOMADA
• Origin：China
• Production Capacity：50000PCS,Year

Chassis model

P450 10X4

Wheelbase mm

1940+4160+1445+1305

Maximum engine power kW/ (r/min)

332/1900

Maximum engine torque N. m/ (r/min)

2350/1000-1300

Vehicle mass Kg

54080

Overall vehicle dimensions (length X width X height) mm

15835 X 2530X 3980

Maximum theoretical conveying capacity m3/h

180

The maximum outlet pressure of concrete MPa

11.3

Hydraulic system type

Closed

Boom structure

63X-6RZ

Fabric height m

62.6

Maximum cloth radius m

57.6
