• Model NO.：AMP4000-C
• Certification：ISO9001: 2000
• Condition：New
• Transport Package：by Sea Required
• Specification：ISO
• Trademark：kudat
• Origin：China
• HS Code：84743200
• Production Capacity：10sets,Month

Basic Info.

Model NO. AMP4000-C Certification ISO9001: 2000 Condition New Transport Package by Sea Required Specification ISO Trademark kudat Origin China HS Code 84743200 Production Capacity 10sets/Month

Product Description

AMP4000-C Mobile Asphalt Mixing Plant
Illustration: The plant is designed for a production of 280~320 t/h of road mix asphalt with a finished product temperature of 160º C, under the following standard conditions:

· Maximum production: 320 t/h
· Rate output included aggregate, bitumen and filler
· Maximum mixing capacity: 4, 500 kg / batch
· Aggregate bitumen ratio accuracy: ≤ ± 0.3%
· Bitumen weighing accuracy: ≤ ± 1% (Continuous real-time detect)
· Aggregate weighing accuracy: ≤ ± 2% (Continuous real-time detect)
· Filler weighing accuracy: ≤ ± 2% (Continuous real-time detect)
· Aggregate temperature accuracy: ≤ ± 3º C
· Fuel consumption (diesel): ≤ 6.5 kg/t
· Working environment noise level: ≤ 80 db(A)
· Noise level in control room: ≤ 70 db(A)
· Dust emission (Filter bag system): ≤ 90 mg/Nm3
· Standard layout area approx. 48 m x 40 m (Flexible to be adjusted to fit actual job site limitation)
· Working voltage: 380V/50 HZ
· Operation: Automatic / Manual / Fully computer controlled
· Operation voltage: 922 kW
· Desired environment temperature: 20 ~ 50º C
· Working altitude level: <2, 500 m
· Aggregate moisture content; ≤ 5%
· Aggregate density; 1, 700 kg/m3
· Aggregate sandiness rate ≤ 45%
· Filler moisture content ≤ 1%, and not block
· Gradation of aggregate should be continue.
· Ph value: ≥ 7
· Fuel Calorific value ≥ 9500kcal/kg
· Material not porous and hygroscopic with normal shape

Any deviation of above-mentioned working condition may cause fluctuated production of plant.

1.0 Cold Feed System

· Imported Frequency Converter Controller for Belt Feeders, places typical magnetic speed controller.
· Speed adjustment of Frequency Converter in control room, easy operates, visible on screen, reliable operation, stable accuracy adjustment, and low malfunction performance.
· No flow switches for every hopper, signal to control room for run out of aggregate or blockage.
· Vibrators for sands hoppers, avoid material blockage; Oversize meshes for hoppers, avoid large aggregate to system, provides reliable operation of system.
· Equipped with pre-vibrated screen device, located at inlet position of Inclined Conveyor, screen out large aggregate without enter Dryer Drum, effectively reduces foul material of system.
· Reduce foul material benefits save energy, increase heat efficiency, protect Dryer Drum, increase reliable operation of Hot Elevator and Screen Deck, and finally increase working life of equipment.

1.1 Cold Feed Hoppers

Quantity: 5 sets
Capacity: 12 m3
Loading width: 3.5 m
Loading height: 3 m

1.2 Belt Feeders

Quantity: 5 sets
Conveyor capacity: 150 t/h of each set (max. )
Belt width: 800 mm
Drive: 3 kW of each set

Model No.:	AMP4000-C
Product Origin:	China
Price Terms:	FOB, CIF
Payment Terms:	L/C, T/T
Supply Ability:	10sets/month
Minimum Order:	1set
Delivery Lead Time:	30 days
Certification(s):	ISO9001, ISO14001, OHSAS18000
