• Model NO.：ZE210E
• Size：Medium-Sized
• Certification：CE, ISO9001: 2000
• Condition：New
• Rated Power：112,1950kw,Rpm
• Max. Torque：614,1500n.M,Rpm
• Digging Force of Bucket (ISO)：147kn
• Digging Force of Stick (ISO)：103kn
• Max. Excavating Radius：9830mm
• Max. Excavating Distance：9650mm
• Transport Package：Nude Package
• Specification：21300kg
• Trademark：Zoomlion
• Origin：China
• HS Code：8429521200
• Production Capacity：100units,Month

Overview Product Description

Product Parameters



 ItemUnitZE210EKey ParameterWorking masskg21300Rated powerkw/rpm112/1950Standard bucket capacity (SAE)m30.9System flow (Max. pressure/ Max. flow)-32.1/35 Mpa 2×206 L/minEngine model-Cunmins B5.9-C(150hp)Max. torqueN.m/rpm614/1500Traveling speed (low/high)km/h3.3/5.5Slewing speedrpm11.5Gradeability°°35°Max. drawbar pullkN192Digging force of bucket (ISO)kN147Digging force of stick (ISO)kN103Basic ParameterSlewing radius of tailmm2840Tail lengthmm2800Counterweight ground clearancemm1050Min. ground clearancemm440Ground contact lengthmm3380Track lengthmm4180Track gaugemm2200Track widthmm2800Track shoe widthmm600Height of grousermm26Slewing table widthmm2720Operating RangeMax. excavating radiusmm9830Max. excavating distancemm9650Max. excavating heightmm9615Max. discharging heightmm6785Max. excavating depthmm6610Max. vertical excavating depthmm5760Min. slewing radius of frontmm3290 Detailed Photos

Company Profile
