• Model NO.：RP601
• Condition：New
• Transport Package：Nude
• Specification：CE, ISO, GHOST
• Trademark：XCM
• Origin：China
• HS Code：8426990000
• Production Capacity：50 Sets,Month

Basic Info.

Model NO. RP601 Condition New Transport Package Nude Specification CE, ISO, GHOST Trademark XCM Origin China HS Code 8426990000 Production Capacity 50 Sets/Month

Product Description

Compact type Reliable Efficient
Advanced screed technology
Minimum 2.5m Max 6m
Excellent performance wide application
The imported engine with original packing has strong power, and can meet the requirements of high-efficient work.
- Precise matching design with advanced energy conservation control can reduce the oil consumption of the machine.
- Low emission meets the Europe II standard.
- The adoption of new cooling fan and large-scale silencer lowers the noise of the machine.
- The adoption of the advanced turbocharging technique increases the highland adaptability of the machine.
- Automatic preheating system improves the working capacity in the low temperature.
- Unique fan cover with the shape of hopper opening greatly improves the air supply of the engine and the radiating capacity of the system, guaranteeing the successive high-efficient work of the machine.
- Restart prevention system effectively avoids the misoperation, and improve the use security of the machine.
The imported engine with original packing has strong power, and can meet the requirements of high-efficient work.
- Precise matching design with advanced energy conservation control can reduce the oil consumption of the machine.
- Low emission meets the Europe II standard.
- The adoption of new cooling fan and large-scale silencer lowers the noise of the machine.
- The adoption of the advanced turbocharging technique increases the highland adaptability of the machine.
- Automatic preheating system improves the working capacity in the low temperature.
- Unique fan cover with the shape of hopper opening greatly improves the air supply of the engine and the radiating capacity of the system, guaranteeing the successive high-efficient work of the machine.
- Restart prevention system effectively avoids the misoperation, and improve the use security of the machine.

Items	Unit	Parameters
Basic paving width	m	2.5
Max. paving width	m	6
Max. paving thickness	mm	150
Paving speed	m/min	0~3.6
Travel speed	km/h	0~11
Theoretical Productivity	t/h	300
Hopper Capacity	t	13
Gradeability	%	20
Pavement evenness	mm/3m	3
Transverse levelling accuracy	%	±0.03
Centre crown ratio	%	0~+3
Engine model		D4114ZG2B
Engine power	kW	100
Engine speed	r/min	2400
Machine weight	t	17.4
Dimension	mm	6400X2580X3830
Vibrator speed	r/min	0~1470
Screed heating		Gas heating
Auger and conveyor control		Automatic Control by Ultrasonic Sensors
Automatic levelling control		Simulation control of electronic automatic leveler



Items	Unit	Parameters
Screed model	/	475Q
Type	/	Single vibrator+Gas heating
Extension	/	Hydraulic+Mechanical assembly
Width	m	2.5~6.0
Vibrator speed	r/min	0~1470
Vibrator amplitude	mm	4
Extra-long screed	mm	625
