L918f 0.8m3 Standard Bucket 1.4t Wheel Loader for Construction

Evangel Industrial (Shanghai) Co., Ltd.
  • After-sales Service：Provide
  • Warranty：1 Year
  • Certification：TUV, UL, ISO, RoHS, CE
  • Condition：New
  • Rated Load：1-3t
  • Transmission：Hydraulic

Base Info

  • Load and Unload Mode：Front Discharge
  • Walking Mode：Wheeled
  • Type：Small Loader
  • Transport Package：Sea
  • Origin：China

Description

Overview  Contact Information

Product DescriptionOverall dimensionL*W*H5850*2140*2920mmWheel base2260mmMin. ground clearance290mmMax. dumping height2420mmDumping distance1125mmDumping angle45wheel tread1630mmsteering angle32horizontal crossing radius5340mmMin. turning radius4770mmOverall parametersBacket capacity0.8 m3Rated load1400kgoperating weight6540kgMax. tractive force57kNMax. breakout force38kNTipping load35kNEngineModelTCD3.6 L4TypeTurbocharged and intercooled, common railRated power55.4kWRated speed2300r/minEngine displacement3620mlClylinder bore/stroke4Max. torque390N.mEmission standardStage IV/Tier 4Min. fuel-consume ratio204g/kw.hTransmission systemTorgue convertersingle-stage three-element
single-turbine torque converterTransmission typeAxis-fixed electro-hydraulic transmissionGearsForward 2 reverse 2Hydraulic system of working deviceTypeHydraulic pilot controltotal time8.11sBrake systemService brake typeFully hydraulic disc brakeParking brake typeManual control internal expanding shoe brakeSteering systemTypeLoad sensing full hydraulic articulated steeringSystem pressure12 MpaFill capacityFuel120LHydraulic oil102LEngine10LTransmission20LDrive axleForward 10L+ reverse 10LBraking system4L
