• Model NO.：W156
• Type：Medium-sized Loader
• Front Loader：Front End Loader
• Operation Weight：16200kg
• Engine Brand：Cummins or C6121
• Gearbox：Zl50 Planet Type
• Gear Shifts：F2,R1
• Service Brake：Air Active Oil, Brake Shoe with Disc
• Transport Package：in Container
• Specification：CE Gost-R ISO
• Trademark：WORLD
• Origin：China
• HS Code：84295100
• Production Capacity：5000 PCS,Year

Main Standard ConfigurationBucket Capacity3.0 CBMRated Load5000kgTravelling Speed
 Forward 1st0-11.5km/hForward 2nd0-37.5km/hReverse 1st:0-17km/hMax. Traction165kNMax. Break Out Force150kNMin. Turning Radius (outside tires)6700mmMax. Dumping Height3100mmMax. Reach1200mmTotal Hydraulic Cycle Time≤ 11.1sFull Bucket Lifting Time5.7sDimensions (LxWxH)8075x2960x3500mmMin. Clearance Over Ground380mmOperating Weight16200kg

 Diesel Engine
 ModelDongfeng CUMMINS 6CTA8.3 or Shangchai C6121 or Weichai SteyrTypeDirect injection, turbocharged, water cooling, 4 strokes, 6 cylindersRated Output160kW/162kW/162kWRated Speed2200rpmMax. Torque855/860/908N. m

 Transmission
 ModelZL50ManufacturerHangzhou Advance Gearbox Group Co., LtdRated Input Power154kWRated Input Speed2200rpmHydraulic Torque Converter ModelSingle stage, two phase four componentsTorque Ratio When Zero Speed4Transmission Typetwo forward and one reverse gears/power shift, planet type

 Mechanical Gear Ratios
 Gear I2.4346Gear II0.6532Reverse1.7814

 I. O. Gear Ratio Of P. T. O.
 P. T. O. 11.00P. T. O. 21.167Hydraulic Oil Pressure:1.10-1.40MPaInlet Oil Pressure Of Torque Convertor 0.30-0.45MPaOutlet Oil Pressure Of Torque Convertor0.20-0.30MPaLubricating Oil Pressure0.10-0.20MPaMax. Permissible Temp & Outlet Of Torque Convertor120 degree

 Transaxle & Tire
 Transaxle Typeself-made by Meritor technologyDrive System4 wheel drive Drive RatioBitmap
22.85Rear Axle OscillationCenter oscillationOscillating Angle Of Rear Axle                                                   13°Carrier Assembly Reduction Ratio4.625Wheel End Reduction Assembly Reduction Ratio4.94Tire23.5-25Pressure Of Tire0.28-0.32MPa

 Working Hydraulic System
 Working Pump TypeGear PumpSystem Working Pressure17 MPaWorking Pump Max. Flow Rate  328 l/minLifting Cylinder Bore x Stroke165x757mmTilting Cylinder Bore x Stroke200x540mm

 Steering System
 TypeArticulation, full hydraulic power steering system with flow-amplified systemSteering Pump Type    gear pump (Model: CBGj2080)Max. Flow Rate43L (1920r/min)Max. Working Pressure12MPaSteering Cylinder Bore x Stroke100x342mmMax. Steering Angle35°

 Brake System
 TypeAir over hydraulic disc on four wheels brakesDrive Brake System Pressure0.71-0.784MPaParking Brakeinner expanding shoe brake, air cylinder and spring energy reverse, applied via a switch on the control stand panel

 Oil Injection Capacity
 Fuel Tank300LEngine Oil30LTransmission45LHydraulic Oil Tank200LTransaxle30L
