• Model NO.：LW500KL
• Transport Package：in Nude
• Specification：ISO; CE
• Origin：Jiangsu, China
• HS Code：8701100000
• Production Capacity：3000

Strong structure
Heavy load for the rocky condition; the working device and front and rear frame feature thick board of high strength, reasonable distribution and strong carrying capacity.
The large rock bucket with capacity of 3.0m³ is improved in terms of the work efficiency and adaptation. The bucket teeth adopt the structure of toothholder and sleeve. The cutting blade and bucket edge are equipped with protection device, featuring excellent abrasion resistance and shock resistance.
The thickness of the front frame lug and baseboard is 70mm, and the thickness of the up and down articulated board is 30mm. The machine is superior among the products of same kind in terms of the structural strength and carrying capacity.
Large distance between up and down articulated boards, and large maintenance space. Resolve the load horizontally and vertically efficiently. Easier to access, the machine has more carrying capacity and larger opening space.
Each part passes the scientific analysis with professional stress analysis software to ensure that the reliability and carrying capacity of the structural parts could reach the design standard and meet the requirement of the tough condition.
2. Parameter
Item
LW500KLParameter
Unit
Rated load
5000
kg
Tipping load
110
kN
Bucket capacity
3.0
m
Dumping height
3090
mm
Dumping distance
1130
mm
Lifting height
5262
mm
Bucket width
3000
mm
Max.drawing force
170
kN
Max. traction
175
kN
Articulation angle
±38
°
Dimension (Length × Width × Height )
8185×3000×3465
mm
Operating weight
17.4
t
Boom lifting time
≤6
s
Total time of three devices
≤11
s
Wheelbase
3300
mm
Tread
2250
mm
Min. turning radius(tyre center)
5925
mm
Min. turning radius (bucket outside)
6910
mm
Rated power/rotary speed
162/2200
kW/r/min
Engine model
WD10G220E23
Gradeability
30
°
Speed
I Gear (Forward/Backward)
11/13
km/h
II Gear (Forward)
36
km/h
Tyre specification
23.5-25-16PR
