• Model NO.：XE40
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Standard Bucket Capacity：0.14 M3
• Engine Model：4tnv88
• Dimension：1650*2440*1500 mm
• Rated Power/Speed：27.1,2200 Kw,Rpm
• Main Pump：Japan NACHI
• Max. Dumping Height：3700 mm
• Max. Digging Depth：3600 mm
• Max. Vertical Wall Digging Depth：2250 mm
• Travel Speed：4.2,2.6 Km,H
• Transport Package：Suitable Package for Shipment
• Specification：CE, ISO
• Trademark：ORIEMAC
• Origin：Xuzhou, China
• HS Code：84295212
• Production Capacity：100 Units,Month

Operating weightkg4050Standard bucket capacitym³0.14EngineEngine Model/4TNV88Direct injection/√Four strokes/√Water cooling/√Turbo charged/×Air to air intercooler/×No. of cylinders/4Rated power/speedkw/rpm27.1/2200Max. torque/speedN.m142/1320DisplacementL2.19The main performanceTravel speedkm/h4.2/2.6Swing speedr/min13.5Max. gradeability/30Ground pressurekPa36.3Max.Bucket digging force kN23.2Max.arm crowd force kN19.3Max.traction force 33.9Hydraulic systemMain pump/
Japan nachi
 Rate flow of main pumpL/min1×110+11Max pressure of prime relief valveMPa21Max pressure of travel systemMPa21Max pressure of swing systemMPa21Max pressure of pilot systemMPa3.9Fuel tank capacityL65Oil capacityHydraulic tank capacityL70Engine lubricationL7.4A Overall lengthmm5455Overall dimensionsB Overall widthmm1650C Overall heightmm2440D Overall width of upperstructuremm1500E Track lengthmm2198F Overall width of undercarriagemm1635G  crawer widthmm300H Dozer black(width/height)mm1650×300I Tumbler distancemm1721J Crawer gaugemm1335K Clearance under counter weightmm578L Ground clearancemm350M Min.tail swing radiusmm1480A Max. digging heightmm5320Working rangeB Max. dumping heightmm3700C Max. digging depthmm3600E Max. vertical wall digging depthmm2250F Max. digging reachmm5810G Min. swing radiusmm2385H Max.dozer lifting heightmm255I Max.dozer cutting depthmm375 Angle of arm deflection Degree/

ABOUT US:
As a leading Chinese exporter of construction machinery and trucks, we have a professional experience of 8 years in this field. Besides our products of high quality, our international sales team will also provide you excellent logistics service and after-sales service.  We will always do our best to solve all the problems and put our customer's interests in the first place.


We can supplier all kinds of trucks and construction machinery.

ANY QUESTIONS JUST CONTACT ME PLEASE!
