Small Backhoe Loader Wz30-25
Evangel Industrial (Shanghai) Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Type：Universal Type
- Transmission：Power Transmission
- Walking Mode：Wheeled
- Load and Unload Method：Front Discharge
Base Info
- Model NO.：WZ30-25
- Engine Power：<74kw
- Certification：CE, ISO9001: 2000
- Condition：New
- Color：Yellow
- Operating Weight：7300kg
- Model：Xt870
- Bucket Capacity：1.0m3
- Usage：Construction
- Power Source：Diesel
- Transport Package：Standard Package for Shipment
- Specification：ISO
- Trademark：EON
- Origin：Jiangsu, China
- Production Capacity：600 PCS,Month
Description
Description
Specifications
Unit
Working weight
7300
kg
Overall dimensions(L*W*H)
7173*2366*3437
mm
Max.travels speed
40.2/48.6
km/h
Wheel base
2152
mm
Turning radius
4428
mm
Tires(F/R)
12-16.5/19.5L-24
Working oil pump
Oil pump model
KP30.15
Max travel speed
2200
r/min
Rated pressure
21
Mpa
Engine
Rated power
74
kw
Rated speed
2200
r/min
Model
B4.5T
Modality
4-cycle. Turbocharger.water cooled.4-cylinder
Overall displacement
4.5
L
Fuel consumption
225
g/kw.h
Loading installment
Bucket capacity(heaped)
0.8-12
m3
Dumping clearance
2825
mm
Dumping reach
727
mm
Break-out force
42
KN
Excavation installment
Digger capacity
0.25-0.35
m3
Max.digging depth
4495
mm
Max.digging radium
5471
mm
