Pile Driving Machine Hydraulic Pile Driver Piling Machine

Ji Ning Hengwang Mining Machinery Co., Ltd.
  • Type:Vibration Piling Machine
  • Pressure Pile Driver Type:Hydraulic Pile Driver
  • Pile Hammer Type:Hydraulic Hammer
  • Power Source:Diesel
  • Motor Power:40kw
  • Noise:Without Noise

Base Info

  • Certification:CE, ISO 9001:2000, ISO 9001:2008
  • Condition:New
  • Name:Guardrail Pile Driver
  • Application:Guardrail, Fence, Highway
  • Engine Power:40kw
  • Pile:Round or Square Steel Pile
  • Power Head Model:68#
  • Drillig Diameter:0-250mm
  • Drill Depth:2500mm
  • Pile Diameter:50-260mm
  • Pile Max.Length:2800mm
  • Geology:Soil and Rock
  • Transport Package:20" or 40" Container
  • Specification:5000*2000*2700mm
  • Trademark:Hengwang
  • Origin:Shandong, China
  • HS Code:8430100000
  • Production Capacity:500 Sets Per Month

Description

Basic Info.

Certification CE, ISO 9001:2000, ISO 9001:2008 Condition New Name Guardrail Pile Driver Application Guardrail, Fence, Highway Engine Power 40kw Pile Round or Square Steel Pile Power Head Model 68# Drillig Diameter 0-250mm Drill Depth 2500mm Pile Diameter 50-260mm Pile Max.Length 2800mm Geology Soil and Rock Transport Package 20" or 40" Container Specification 5000*2000*2700mm Trademark Hengwang Origin Shandong, China HS Code 8430100000 Production Capacity 500 Sets Per Month

Product Description

Pile Driving Machine Hydraulic Pile Driver Piling Machine

1, the host model:  the domestic standard 20 loader.
2, construction geology: highway, railway guardrail pile driver, (plus air compressor can play rock).
3, the standard diameter: standard diameter 114-180mm, the largest aperture 200mm.
4, configuration air compressor: Recommended 8 cubic air compressor, for the duration requirements, please configure a large air compressor, powerful, fast.
5, the product advantages: four-wheel drive, turbocharged, powerful.


Pile driver Parameter

Model  HW-930
Diesel power(KW)   40
Pile diameter mm 114-220
Pile length m2.6-3.3
Hydraulic system  flow(L/Min)80-110
Rated system pressure(Mpa) 15
wheel track (M)1620
wheel base(M) 2070
Dimension(L*W*H) 3200*2000*2900
Weight(Kg)3400
Pile hydraulic hammer weight((Kg)  80
Hydraulic hammer frequency(Bpm)  500-900
Hydraulic hammer working flow(L/min)40-70
Hydraulic hammer working pressure(Mpa) 11-14
Drill power unit weight(Kg) 60

Machine pictures
