14 Ton Single Drum Hand Lawn Vibro Roller Compactor Sr14 with Best Price
Evangel Industrial (Shanghai) Co., Ltd.- Type：Road Roller
- Working Method：Vibration
- Axle：Biaxial Dual-Drum
- Grinding Wheel Type：Tire Grind
- Compaction Depth：35cm
- Engine Type：Diesel Engine
Base Info
- Model NO.：SR14
- Travel Speed：40cm,s
- Centrifugal Force：40KN
- Certification：CE
- Condition：New
- Operating Weight(Kg)：16000kg
- Engine Model：Sc4h140.1g2
- Rated Power(Kw/Rpm)：103,1800
- Transport Package：Nude Package
- Specification：6150*2300*3200MM
- Trademark：Evangel
- Origin：China
- Production Capacity：100 Sets,Month
Description
Parameter name
SR14
Operating weight (Kg)
14000
Exciting force (KN)
310/200
Vibration frequency (Hz)
30/35
Nominal amplitude (mm)
1.65/0.70
Gradeability (%)
45
Engine model
Weichai WP6G140E22
Rated power/rated speed (kW/rpm)
105kw/2200rpm
Overall dimensions of machine (mm)
6140*2280*3100
Forward speed (km/h)
F1: 0-5.5, F2: 0-10
Reversing speed (km/h)
R1: 0-5.5, R2: 0-10
Fuel tank (L)
240
Compacting width(mm)
2130
