Electric Concrete Vibrator (ZN50 ZN70 ZN90)

Ningbo Ace Machinery Co., Ltd.
  • Type：Concrete Vibrator
  • Shotcrete Type：Semi-Dry
  • Machining Process：Assembly
  • Structure：Rotor Type
  • Productivity：60m²,h
  • Feeding Height：1370mm

Base Info

  • Model NO.：ZN50 ZN70 ZN90
  • Vibrating Amplitude：0.9mm
  • Certification：ISO9001: 2000, CE
  • Condition：New
  • Color：Yellow
  • Product Name：Electric Concrete Vibrator
  • Power：1.1kw (1.5HP)
  • Voltage：220V
  • Net Weight：20kgs
  • Matched Vibrator Shaft：32mm,38mm,45mm,60mm
  • Lenght：3~6mtr
  • Packing Size：43*26*33cm
  • Transport Package：carton
  • Specification：CE
  • Trademark：KZW
  • Origin：China
  • HS Code：84306100
  • Production Capacity：5000 pcs,month

Description

ITEMConcrete vibrator motorTypeJapanese type/Dynapac typewith Frame typeModelZNS50ZNS70ZN50FGZN70FGPower, (HP)1.52.01.52.0Voltage, (V)220/110V220/110V220/110V220/110VFrequency, (HZ)50505050Current, ()7.89.47.89.4Workingspeed(RPM)2840284028402840PACKING SIZE(cm)44*25*3347*25*3342.5*25*27.742.5*25*27.7Weight (kgs)20221718
Concrete vibrator shaftModel¢(mm)ZX35ZX-38ZX-45ZX-50ZX-60ZX-70Diameter of head¢(mm)353845505070Length of headL (mm)380420420480410450Vibrating Frequency(HZ)183185185200200200Vibrating Ampitude(mm)0.9111.21.151.151.35Dia of flexiable hoseD(mm)303032363636Diaof flexiable shaftD(mm)101010131313Weight (6mtr)(kg)141516202124packing sizeCM75*75*5.5
