Russia Type Deep Vibrator 1.4kw / 1.6kw / 2.2kw

Ningbo Ace Machinery Co., Ltd.
  • Type：Concrete Vibrator
  • Shotcrete Type：Semi-Dry
  • Machining Process：Assembly
  • Structure：Rotor Type
  • Productivity：75m²,h
  • Feeding Height：1370mm

Base Info

  • Model NO.：VN10, VN14, VN16
  • Vibrating Amplitude：1.3mm
  • Certification：ISO9001: 2000, CE
  • Condition：New
  • Color：Gray+Red
  • Product Name：Deep Vibrator
  • Power：1.0kw,1.4kw,1.6kw,2.2kw
  • Voltage：42V ,220V
  • Working Speed：3000 Rpm
  • Matched Vibrator Head：32mm,38mm,51mm,75mm
  • Matched Vibrator Hose：3.0mtr ,4.5mtr,6.0mtr
  • Export：Russia ,Ukraine,Hazakstan
  • Transport Package：Carton
  • Specification：1.4KW
  • Trademark：kzw
  • Origin：Ningbo, China
  • HS Code：84294090
  • Production Capacity：3000 pcs,month

Description


ItemConcrete vibrator Engine modelVN-10VN-14VN-16VNS-10VNS-14VNS-22Power, (KW)1,01,41,61,01,42.2Voltage, (V)424242220220220Frequency, (HZ)505050505050Current, ()1624267.027,0813.5Working speed(RPM)300030003000300030003000PACKING SIZE(cm)38*22*32.538*22*32.538*22*32.538*22*32.538*22*32.538*22*32.5Weight121314.51415.616.5

 Vibrator headVibrator hoseModelZX-51ZX-753.0Mtr4.5Mtr6MtrDiameter(mm)5175   LengthL(mm)440450   Vibrating Frequency(HZ)200200   Vibrating Ampitude(mm)1.21.4   Diameter of flexiable hoseD(mm)  363636Diameter of flexiable shaftD(mm)  141414Weight(kg)4.187.8811.515packing sizecm46*29*12/42*24*16/60*05*4.560*65*4.575*75*4.510pcs6pcs
