Lovol Wheel Loader FL958g-II (5ton) for Algeria Market
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Certification：TUV, UL, ISO, RoHS, CE
- Condition：New
- Rated Load：3-6t
- Transmission：Hydraulic - Mechanical
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
Base Info
- Model NO.：FL958g-II
- Type：Medium-sized Loader
- Product Name：Lovol Wheel Loader FL958g-II (5ton) for Algeria Ma
- Bucket Capacity：2.7-4.5m3
- Weight：17100kg
- Engine Model：Weichai,Shangchai
- Engine Power：164kw,2200rpm
- Max. Lifting Height：5410mm
- Transport Package：Nude
- Specification：Dimension: 7960*2970*3450mm
- Trademark：Foton Lovol
- Origin：Shandong, China
- HS Code：84295100
- Production Capacity：1000sets,Month
Description
Basic Info.
Model NO. FL958g-II Type Medium-sized Loader Product Name Lovol Wheel Loader FL958g-II (5ton) for Algeria Ma Bucket Capacity 2.7-4.5m3 Weight 17100kg Engine Model Weichai/Shangchai Engine Power 164kw/2200rpm Max. Lifting Height 5410mm Transport Package Nude Specification Dimension: 7960*2970*3450mm Trademark Foton Lovol Origin Shandong, China HS Code 84295100 Production Capacity 1000sets/MonthProduct Description
Hot Sale Foton Lovol FL958g 5ton Wheel Loader
1. Weichai/Shangchai162kw engine
2. Bucket capacity 3cbm
3. Operating weight 17100kg
4. AC cab
| Parameter Items | Parameter Value |
| 1.Main parameter | |
| Rated load (KG) | 5000 |
| Operating Weight (standard) (KG) | 17100 |
| Rated Bucket Capacity (m3) | 3 |
| Maximum breakout force (KN) | 185 |
| Maximum traction force (KN) | 160 |
| Total hydraulic cycle time (S) | 10.6 |
| Maximum dump height (mm) | 3180 |
| Maximum dump distance (mm) | 1160 |
| Forward speed range (KM / H) | 0~38.4 |
| Back speed range (KM / H) | 0~24.2 |
| Transport dimensions (L × W × H) (mm) | 7960×2970×3450 |
| Maximum steering angle (°) | 37 |
| Max grade ability(°) | 30 |
| Minimum turning radius (mm) | 6770 |
| Tire Size | 23.5-25-16PR |
| 2.Engine parameter | |
| Model | Weichai WD10G220E23 |
| Type | 6-cylinder, in-line, direct injection and turbocharged |
| Power (KW) | 162 |
| Maximum torque (N.M) | 930 |
| Cylinder diameter (mm) | 126 |
| Stroke (mm) | 130 |
| Displacement(L) | 9.756 |
| Fuel consumption (G / Kw.h) | 220 |
| 3.Hydraulic system | |
| Work system pressure (Mpa) | 20 |
| 4.Braking System | |
| Running braking system type | Single pipe air-oil 4-wheel clipper disc braking |
| Parking / emergency brake system type | Drum braking |
| 5.Fuel Tank Capacity | |
| Fuel tank (L) | 280 |
| Hydraulic Tank capacity (L) | 210 |
