Mobile Self Loading Concrete Mixer Truck with High Quality

Shanghai Mineral Industrial Co., Ltd

Type：Concrete Mixing Truck
Shotcrete Type：Wet
Machining Process：Hydraulic
Structure：Cylinder Type
Productivity：4m3,H
Feeding Height：1400mm

Base Info

Model NO.：ct
Vibrating Amplitude：2.4mm
Condition：New
Transport Package：Roro
Specification：CE
Trademark：super-above
Origin：Jiangsu, China
HS Code：8705109100
Production Capacity：1000PCS,Year

Description

CatagoryItemUnitParameterOverall ParameterModel G04K Curb weightkg6905Max.total weightkg16000Outline dimension(L×W×H) mm7270×2280×3345 Chassis model NXG3160D3AZAXSteering position LHD Driving type 4×2Wheel base mm3800Tire 10.00R20Power take-off FlywheelEngineModel YC6J190-33Max.powerkW140DisplacementL6.494Drum systemGeometric volumem³ 7.7Agitating volumem³ 4 Max.diameter of drum mm1980Mixing drum length mm3595Slanting angle°15Rotating speedr/min0~14Feeding speedm³/min≥ 3Discharge speedm³/min≥ 2Discharge residual rate %< 0.4Slump scopemm50~210
