High Quality 2 Ton Wheel Loader Lw922
Jinan Sinoheng Import and Export Co., Ltd.- Certification：CE, ISO9001: 2000
- Condition：New
- Rated Load：1-3t
- Transmission：Power
- Walking Mode：Wheeled
- Type：Small Loader
Base Info
- Model NO.：LW922
- Rated Loading：2000kg
- Rated Bucket Capacity：1.1m 3
- Engine：Changchai4g33
- Gear Shift：2 Gears Ahead,2 Gear Astern
- Usage：Universal Type
- Scraper Type：Tractor-Scraper
- Load and Unload Method：Front Discharge
- Color：Yellow
- Engine Power：70kw
- Transport Package：Nude Packing
- Specification：CE, ISO9001
- Trademark：SINOHENG
- Origin：China
- HS Code：8429510000
- Production Capacity：500 Units,Month
Description
Basic Info.
Model NO. LW922 Rated Loading 2000kg Rated Bucket Capacity 1.1m 3 Engine Changchai4g33 Gear Shift 2 Gears Ahead,2 Gear Astern Usage Universal Type Scraper Type Tractor-Scraper Load and Unload Method Front Discharge Color Yellow Engine Power 70kw Transport Package Nude Packing Specification CE, ISO9001 Trademark SINOHENG Origin China HS Code 8429510000 Production Capacity 500 Units/MonthProduct Description
High Quality 2 Ton wheel loader LW922SINOHENG Wheel Loaders, Loading capacity ranges from 1.6 ton to 6.0 ton including popular models LW16F, ZL20F, 836, 856, ZL50G, LW966, etc.
Detailed Product Description of wheel loader LW922
1, Good cost performance: Adopting full hydraulic transmission, it can bring the power of engine into full play amply. Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission. It enables the loader working efficiency and easy maintenance
2, High productivity: Perfectly designed to enable the machine have super lifting force and automatic leveling at high position.
3, Good capability in climbing the slope: 4-wheel driven, strong driving power.
| Specification | overall weight(kg) | 5200 |
| L×W×H(mm) | 5800×1900×2700 | |
| bucket capacity(m3) | 1.1 | |
| Rated load(kg) | 2000 | |
| dump height (mm) | 3100 | |
| Wheelbase | 2140mm | |
| thread | 1465mm | |
| Max breakout force | 45.4KN | |
| Total time | 9s | |
| Bucket indicator | Yes | |
| Engine | Standard engine | Changchai4G33 engine |
| Type | Vertical, In-line , Water cooling, four-stroke diesel engine | |
| Rated power(kw) | 70KW | |
| Rated speed(r/min) | 2400 | |
| Transmission system | Model of torque converter | YJ265 |
| pattern | 3 element single stage | |
| Gearbox type | Fixed-spindle power shift | |
| Gear shift | 2 gears ahead,2 gear astern | |
| Max travel speed | 24km/h | |
| Hydraulic system | Working pump | CBG2040 |
| Working pressure | 16Mpa | |
| Distribution valve | DF15.2C | |
| Axle | Main reducer pattern | Arc taper gear, moderation of first grade |
| Pattern of wheel reduction | Planet gear moderation of single | |
| Steering system | Type | hydraulic steering |
| Min turning radius(mm) | 4500 | |
| Max turning angle | 35°±1 | |
| Tires | Standard tyres | 16/70-20 |
| Break system | Service brake type | Air assisted oil disc on four wheel |
| Parking brake type | Soft axle control, outside bunch drum type |
