• Model NO.：SM50T-3
• Certification：ISO9001: 2000, CE
• Condition：New
• Milling Width：500mm
• Milling Depth：180mm
• Transport Package：Nude Package
• Specification：3105*2075*2340mm
• Trademark：Shantui
• Origin：China
• HS Code：8429510000
• Production Capacity：50000PCS,Year

Basic Info.

Model NO. SM50T-3 Certification ISO9001: 2000, CE Condition New Milling Width 500mm Milling Depth 180mm Transport Package Nude Package Specification 3105*2075*2340mm Trademark Shantui Origin China HS Code 8429510000 Production Capacity 50000PCS/Year

Product Description

Drive system

103kW power works with 6.6t operating weight to achieve powerful operating capacity and good working condition adaptability.

High traction force and powerful large-depth milling capability.

Working device

The optimized cutter arrangement and excellent manufacturing accuracy guarantee low operating vibration of machine.

Control system

The standard controller and display feature high intelligence level and convenient human-machine interactions.

Parameter name	SM50T-3 (Standard version)
Performance parameters
Operating weight (Kg)	6600
Transport weight(Kg)	6280
Maximum milling width (mm)	500
Maximum milling depth (mm)	180
Engine
Engine model	WP4.1
Rated power/rated speed (kW/rpm)	103/2300
Overall dimensions
Overall dimensions of machine (mm)	3105*2075*2340
Driving performance
Traveling speed (km/h)	0-8
Working speed (m/min)	0-50
Conveyor System
Width of conveyor belt (mm)	-
Swing angle of conveyer (Rightward/leftward) (°)	-
Tank capacity
Fuel tank (L)	180
Working device
Number of milling cutters (Piece)	54
