5 Ton Wheel Loader Zl50gn Rock Bucket Price

Evangel Industrial (Shanghai) Co., Ltd.

Certification：ISO
Condition：New
Rated Load：3-6t
Transmission：Hydraulic
Load and Unload Mode：Front Discharge
Walking Mode：Wheeled

Base Info

Model NO.：ZL50GN
Type：Small Loader
Transport Package：Nude Sea Package
Specification：8225*3016*3515mm
Trademark：EVANGEL
Origin：China
Production Capacity：100units,Month

Description

ItemSpecificationUnitRated operating load5000kgBucket capacity2.5~4.5m³Machine weight17500±300kgDump clearance at maximum lift3100~3780mmReach at maximum lift1100~1220mmWheel base3300mmTread2250mmMax.breakout force175±5kNHydraulic cycle time-raise6sTotal hydraulic cycle time10.5sMin. turning radius over tyres5925±50mmArticulation angle38°Gradeability30°Tyre size23.5-25-16PR Overall machine dimension L×W×H8225×3016×3515 ModelWD10G220E21 Rated Power162KwTravel speedI-gear(F/R)13/17km/hII-gear(F)41km/h
Please contact:

Mobile/ : +86-17705652725
