| Engine | | DCEC 6CTAA8.3-C215 |
| Rated Power | (kW) | 160(215)@2200 |
| Blade Width | mm(inches) | 3960(156) |
| Maximum Speed | km/h (mph) | 40.3 (25) |
| Draw Bar Pull | (kN) | 86 |
| Operating Weight | kg(Lb) | 16500(36376) |
| ENGINE |
| Tier | | II |
| Make | | |
| Gross Power | kW(Hp)@rpm | 160(215)@2200 |
| Net Power | kW(Hp)@rpm | 144(195)@2200 |
| Peak Torque | | 908N.m/1500rpm |
| Torque Rise % | | 31% |
| Number of Cylinders | | 6 |
| Aspiration | | turbo air-to-air aftercooled |
| TRANSMISSION |
| Transmission Type | | power shift |
| Transmission Configuration | | 6f/3r |
| Torque Converter | | three-member single turbine |
| Maximum Travel Speed, fwd | (km/h) | 42 (25.8) |
| Maximum Travel Speed, rev | (km/h) | 25.6 (15.9) |
| Number of Speeds, fwd | | 6 |
| Number of Speeds, rev | | 3 |
| AXLES |
| Front Axle Make | | LiuGong Weld axle |
| Rear Axle Make | | Meritor |
| Differential Type | | No-spin limited slip standard |
| Final Drive Type | | chain drive |
| Axle Oscillation | | ±15° |
| Front Axle Type | | all welded steel frame |
| Front Axle, Wheel Lean Angle | | ±17° |
| STEERING |
| Steering Configuration | | load sensor steering gear |
| Steering Relief Pressure | (Mpa) | 17 |
| Minimum Turning Radius | (inches) | 8000(315) |
| Steering Angle | | ±45° |
| Frame Articulation Angle | | ±20° |
| BRAKES |
| Service Brake Type | | (Dry)shoe |
| Service Brake Location | | rear axle only |
| Service Brake Actuation | | hydraumatic |
| TIRES |
| Tire Size | | 17.5-25 PR12/L3 |
| HYDRAULIC SYSTEM |
| Main Pump Type | | gear |
| Main Relief Pressure | (Mpa) | 18 |
| Pilot Pump Flow | L(Gal)/min | 126(33) |
| WORKING CAPACITIES |
| Maximum Draw Pull | (kN) | 90 |
| Cutting Pressure | kg(Lb) | 8100(17857) |
| TANDEM DRIVE PERFORMANCE |
| Height | mm(inches) | 600(24) |
| Width | mm(inches) | 210(8) |
| Thickness, inner wall / outer wall | mm(inches) | 20/20(0.8/(0.8) |
| Center Distance | mm(inches) | 1538(61) |
| Oscillating Angle | | ±15° |
| MOLDBOARD PERFORMANCE |
| Bank Cut Angle | | 40~70 |
| Moldboard Lift Above Ground | mm(inches) | 405(16) |
| Moldboard Side Shift, right / left | mm(inches) | 725/675(29/27) |
| Maximum Sloping Angle | | 90° |
| Cutting Depth | mm(inches) | 600(24) |
| Circle Rotation | | 360° |
| Circle Diameter | mm(inches) | 1455(57) |
| Circle Thickness | mm(inches) | 140(6) |
| DIMENSIONS |
| Wheelbase | mm(inches) | 6230(245) |
| Overall Length | mm(inches) | 8971(353) |
| Overall Height with Cab | | 3438(135) |
| Overall Width | mm(inches) | 2600(102) |
| Clearance under Front Axle | mm(inches) | 645(25) |
| Moldboard Standard Length | mm(inches) | 4270(168) |
| Moldboard Standard Thickness | mm(inches) | 19(0.7) |
| Moldboard Standard Height | mm(inches) | 650(24) |
| OPERATING WEIGHTS |
| Operating Weight | kg(Lb) | 16500(36376) |
| On Front Wheels | kg(Lb) | 4700(10362) |
| On Rear Wheels | kg(Lb) | 11800(26015) |
| SERVICE CAPACITIES |
| Fuel Tank | L(Gal) | 230(61) |
| Engine Oil | L(Gal) | 22(6) |
| Cooling System | L(Gal) | 45(12) |
| Hydraulic Reservoir | L(Gal) | 186(49) |
| Transmission And Torque Converter | L(Gal) | 45(12) |
| Tandems, Each | L(Gal) | 28(7) |
