• Model NO.：JC60
• Bucket Capacity(M3)：0.5
• Dumping Height(mm)：2400
• Dumping Reach(mm)：750
• Wheelbase(mm)：991
• Bucket Width(mm)：1880
• Rated Power (Kw)：45
• Max. Speed (Km/H)：12
• Transport Package：Container
• Specification：ISO9001: 2000
• Trademark：SINOHENG
• Origin：China
• Production Capacity：500PCS,Month

Model
Main technical parameterJC60AOverall operating height(mm)4000BHeight to bucket hinge pin(mm)3100CHeight to top of cab(mm)2160DHeight to bottom of level bucket(mm)2993EOverall length without bucket(mm)2750FOverall length with bucket(mm)3490GDumping angle at maximum height(°)40HDumping height(mm)2400IDumping reach(mm)750JRollback of bucket on ground(°)30KRollback of bucket at full height(°)104LWheelbase(mm)991MGround clearance(mm)205NAngle of departure(°)20OFront turning radius without bucket(mm)1198PFront turning radius(mm)1958QRear turning radius(mm)1728RRear axle to bumper(mm)1208STread width, centerline to centerline(mm) 1500TWidth(mm)1880UBucket width(mm)1880

Model	JC60
Engine model	498
Bore x stroke(mm)	98×105
Rated power (Kw)	45
Rotating speed(rpm)	2500
Number of cylinders	4
Max. torque  (N.m)	193
Displacement  (L)	3.168
Max. Speed (km/h)	12
Tire(track)  modei	12-16.5
Operating load(kg)	850
Lifting	Arc lifting
Bucket capacity(m3)	0.5
Rated flux(L/min)	75
High Flow Flux(L/min)
Fuel tank capacity(L)	75
Self weight bucket(kg)	3200
