Ce 1000kg 55kw 0.5m3 Skid Steer Loader Jc75
Jinan Sinoheng Import and Export Co., Ltd.- Certification：CE
- Condition：New
- Rated Load：<1t
- Transmission：Hydraulic
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
Base Info
- Model NO.：JC75
- Type：Skid Steer Loader
- Rated Power (Kw)：55
- Operating Load(Kg)：1050
- Bucket Capacity(M3：0.5
- Load and Unload Method：Front Discharge
- Transport Package：5sets, 20′gp
- Trademark：SINOHENG
- Origin：China
- Production Capacity：500 Sets,Month
Description
Model
Main technical parameterJC75 A Overall operating height(mm) 4070 B Height to bucket hinge pin(mm) 3150 C Height to top of cab(mm) 2160 D Height to bottom of level bucket(mm) 2983 E Overall length without bucket(mm) 2880 F Overall length with bucket(mm) 3580 G Dumping angle at maximum height(°) 40 H Dumping height(mm) 2450 I Dumping reach(mm) 710 J Rollback of bucket on ground(°) 30 K Rollback of bucket at full height(°) 104 L Wheelbase(mm) 1115 M Ground clearance(mm) 205 N Angle of departure(°) 20 O Front turning radius without bucket(mm) 1250 P Front turning radius(mm) 2112 Q Rear turning radius(mm) 1774 R Rear axle to bumper(mm) 1082 S Tread width, centerline to centerline(mm) 1500 T Width(mm) 1880 U Bucket width(mm) 1880
Main technical parameter
