China Supplier Marsh Buggies Amphibious Excavators with Floating Pontoon for Salt Lake Dredging

Sinoway Industrial (Shanghai) Co., Ltd.
  • After-sales Service：Available
  • Warranty：1 Year
  • Type：Crawler Excavator
  • Usage：Special Excavator, Marine Excavator, Mining Excavator
  • Bucket：Backhoe
  • Transmission：Hydraulic Transmission

Base Info

  • Model NO.：SWEA260
  • Drive Type：Internal Combustion Drive
  • Bucket Capacity：0.1~0.5m³
  • Size：Medium-Sized
  • Certification：CE, ISO14001
  • Condition：New
  • Boom Reach：10m
  • Engine：Cummins
  • Pontoon Length：10.2m
  • Chain Numbers：3
  • Track Cleats：Alloy Steel
  • Transport Package：Naked
  • Specification：ISO
  • Trademark：SINOWAY
  • Origin：China
  • HS Code：84294990
  • Production Capacity：30 PCS,Month

Description

Basic Info.

Model NO. SWEA260 Drive Type Internal Combustion Drive Bucket Capacity 0.1~0.5m³ Size Medium-Sized Certification CE, ISO14001 Condition New Boom Reach 10m Engine Cummins Pontoon Length 10.2m Chain Numbers 3 Track Cleats Alloy Steel Transport Package Naked Specification ISO Trademark SINOWAY Origin China HS Code 84294990 Production Capacity 30 PCS/Month

Product Description

SINOWAY Amphibious Buggy Excavators
China Supplier Marsh Buggies Amphibious Excavators with Floating Pontoon for Salt Lake Dredging

Machine Show

China Supplier Marsh Buggies Amphibious Excavators with Floating Pontoon for Salt Lake Dredging
China Supplier Marsh Buggies Amphibious Excavators with Floating Pontoon for Salt Lake Dredging
China Supplier Marsh Buggies Amphibious Excavators with Floating Pontoon for Salt Lake Dredging
Machine Introduction
China Supplier Marsh Buggies Amphibious Excavators with Floating Pontoon for Salt Lake Dredging
China Supplier Marsh Buggies Amphibious Excavators with Floating Pontoon for Salt Lake Dredging


Specifications
Engine
ModelIsuzu/Cummins/Doosan
TypeSix-cylinder,water-cooled turbocharged,mechanical injection
Rated power110KW
Main Technical Specification
Operating weight30000Kg
Standard bucket capacity0.9m3
Slewing speed11rpm
Stick digging force97.64KN
Bucket digging force122.85KN
Main Features
Tracked pontoon structure
Big torque travelling device
Big circular arc structure
High capacity of fuel tank
Main Applications
River/Beach earth moving
Swamp works
Dredging applications
Delta works
Waterway deepening
Hydraulic System
Main pumpKAWASAKI
Main valveKAWASAKI
MotorKAWASAKI
Hydraulic flow rate2x210L/min
Hydraulic pressure32MPa
Travelling System
Travelling speed0~5.4km/h
Grade ability65%
Ground pressure0.014MPa
No. of chains300%
Dimensions
Overall length11200mm
Overall width5350mm
Overall height3900mm
Ground clearance1192mm
Length of pontoon8000mm
Width of pontoon1500mm
Height of pontoon1500mm
Optional
Wide bucket
Operating Scope
Stick length2900mm
A: Max. cutting height10577mm
B: Max. dumping height7810mm
C: Max. digging depth5704mm
D: Max. reach10000mm
