• Model NO.：SWADP320
• Bucket Capacity：0.5~1.0m³
• Size：Medium-Sized
• Certification：ISO9001: 2000, ISO14001
• Condition：New
• Operating Weight：36 Ton
• Engine Power：325HP
• Brand：Sinoway
• Model：Swadp320
• Chain Number：Three Strand
• Transport Package：Naked
• Specification：ISO9001
• Trademark：SINOWAY
• Origin：China
• HS Code：84314990
• Production Capacity：20 PCS,Month

Main Technical Specification Operating weight40 tonMax. payload10 tonEngineCumminsType6-cylinders, water cool, turbochargingRated power325hp/2200rpmMax. pressure320MPaMax. flow2×360L/minMain pumpDoosanMulti-way valveDoosanControl valveDoosanTravel motorDoosanTravel speed on land0~3.0km/hTravel speed on water0~1.0km/hGrade ability30°Hydraulic winch's max pulling force20tonHydraulic winch's total rope length50mGround pressure0.125Kgf/cm2Overall size (L×W×H)10200×6200×3500mmWidth of pontoon/length of pontoon2400mm/1800mmPlatform size (L×W×H)8500×6000×2000mmCabinAll-steel broad cab, 360 visual angle,
centralized control operator panel, ratating chair, air conditionerCrane With Foldable Arm Crane capacity8tonMax. lifting range9.7mMax. lifting moment160kN.mMax. lifting height12.3mNo. of telescopic arm sections3pcsRotary rangePros and cons to 360°, continuous rotaion ≤3r/min
