Overall Dimension |
Length(with bucket on ground) | 5835(mm) |
Width (at landing leg) | 2240(mm) |
Width(to the outside of the tire) | 1993(front wheel) 2057mm(rear wheel) |
Bucket width | 2313(mm) |
Height (to the top of the cab) | 2720(mm) |
Height (to the top of the digging arm) | 3548(mm) |
Wheelbase | 2155.5(mm) |
Back wheel tread | 1700(mm) |
Front wheel tread | 1880(mm) |
Min. ground clearance | 355(mm) for 2WD 275(mm) for 4WD |
Min. ground clearance of tail | 350(landing leg), 520(centre) |
Traveling speed (4 forward and 4 reverse gears) |
(1) I gear forward/reverse | 6/6(km/h) |
(2) II gear forward/reverse | 9.6/9.6(km/h) |
(3) III gear forward/reverse | 20.5/20.5(km/h) |
(4) IV gear forward/reverse | 38/38(km/h) |
Loading specification |
Rated loading capacity | 1700kg(standard bucket) |
Operating weight | 8000kg(standard bucket) |
Rated bucket lifting capacity | >34KN |
Bucket capacity | 1.0m3(standard bucket) |
Max. breakout force | >49kN(swinging arm), 60(bucket) |
Max. dumping clearance | 2714mm(standard bucket) |
Max. dumping reach | 845mm(standard bucket) |
Dumping angle at full height | 43.5º(standard bucket) |
Tilting angle of bucket | On ground | 41° |
For transportation | 41.7° (350) |
Max. digging depth (with bucket bottom horizontal) | 80mm |
Min. turning radius (centre of the tire outside) | 4380mm |
Lifting time of loading bucket | ≤4.5(sec.) |
Lowering time of loading bucket | ≤3.5(sec.) |
Dumping time | ≤1.5(sec.) |
Digging specification |
Rated digging bucket capacity | 0.2(m3) |
Max. digging depth | 4405(mm) |
Max. digging force | >56.1±10%kN(bucket lip) |
Max. digging radius | 5390(mm) |
Max. dumping height | 3510(mm) |
Central offset | 550mm |
Swing angle | 180° |
Max. rollback angle of digging bucket | 201° |
Diesel engine |
Model | Cummins/ Perkins |
Type | Direct injection, turbocharged, water-cooled |
Rated output | 74 kW/100HP |
Rated speed | 2200rpm |
Total displacement of cylinder | 4.5(L) |
Cylinder diameter /stroke | 102/138(mm) |
Voltage of starting motor | 12(V) |
Max. torque | 414N.m at 1500rpm |
Starting type | Electric |
Min. specific fuel consumption | 225(g/kW.h) |
Oil Capacity |
Fuel(diesel) | 151(L) |
Engine lubricating oil | 11(L) |
Oil for converter and gear box | 18.5(L) |
Oil for hydraulic system | 110(L) |
Oil for driving axles (F/R) | 7.6+17(L) |
