• Model NO.：LT28T
• Type：Large Loader
• Operating Weight：28 T
• Max. Lifting Height：3600
• Fork Size：1500mm*250mm*120mm
• Wheelbase：4200mm
• Engine：Cummins,Weichai
• Tire Type：26.5r25&26.5-25
• Max.Dumping Height：28tons @3600mm Height, 30tons @1600mm Height
• Rated Power：199kw,2200rpm
• Color：Yellow
• Engine Power：199 Kw
• Transport Package：in Nude
• Specification：9850mm*3130mm*3680mm
• Trademark：LTMG
• Origin：China
• HS Code：84295100
• Production Capacity：500sets,Year

Model LT28TOperating weight kg31,000 kgRated engine power WEICHAIRated rotate speedr/min2200Max.torqueN.m920Max.dumping heightmm28tons @3600mm height,
30tons @1600mm heightRated loadT28Transmission Beilian transmissionNO.of shifts Forward 4 For Reverse 2Forward 1km/h0-7.2Forward 2km/h0-14Forward 3km/h0-27Forward 4km/h0-41Reverse 1km/h0-7.2Reverse 2km/h0-14Grade ability ≥25°Turning angle ±33°Overall lengthmm9850Overall widthmm3130Overall heightmm3680Wheel basemm4200Track basemm2830dimension of forkmm1500*250*120Tire type Front tire: 26.5R25            Rear tire:  26.5-25

1.Exclusive patent:
6 proprietary technologies are applied in our loaders make them more fuel-efficient and safety,
such as Auto Cooling Technology on brake system improve the safety.
And the dust-proof layer make the axle more durable.

2.Details in structure:
Bigger hinge pin and hinge bearing raise the carrying capacity, machine more powerful.
The exclusive dust-proof layer and sealed articulated points make the loader more durable.

3.Novel appearance and humanized design:
Cabin with broad view.
Single (double)-handle pilot control system, electronic control gearshift to ensure easy operation and more comfortable.

4.Hydraulic systems:
To adopt confluence of double pumps and equivalents unloading hydraulic systems, rational use of engine power,
reduce energy consumption effectively.
Independent transmission oil and hydraulic oil cooling improve the hydraulic system stability.

5.Optional attachment:
Floating forks, tire chain, log grapple, block fork, snow blade, grass fork, enlarged bucket and teeth etc.







After sales service

LTMG always treat after-sale service more important than sale.
Nowadays more than 30 agents around the world can supply LTMG professional after-sale service.
All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please check our website and product certificate.
