• Model NO.：GR135
• Transport Package：Nude
• Trademark：XCG
• Origin：China
• Production Capacity：500units

Basic specification
Engine brand
Dongfeng Cummins
Engine model
6BT5.9
Rated power/speed
100/2200kw/rpm
Horsepower
135hp
Dimension(LxWxH)
8015 × 2380 × 3050mm
Operating weight(Standard)
11000kg
Driven axle
Meritor  driven  axle
Cabin
cabin, A/C
Performance specification
Traveling speed ,forward
5,8,13,20,30,42km/h
Traveling speed ,reverse
5,13,30km/h
Tractive force(f=0.75)
61.3KN
Max. gradability
20%
Tire inflation pressure
300kPa
Working hydraulic pressure
16MPa
Transmission pressure
1.3~1.8MPa
Operating specification
Max. steering angle of front wheels
±49 °
Max. lean angle of front wheels
±17 °
Max. oscillation angle of front axle
±15 °
Max. oscillation angle of balance box
16
Frame articulation angle
±27 °
Min. turning radius using articulation
6.6m
B l ade
Maximum lift above ground
410mm
Maximum depth of cutting
535mm
Maximum blade position angle
90 °
Blade cutting angle
28 °_ 70 °
Circle reversing rotation
360 °
Moldboard width X height
3710 × 610mm
