• Model NO.：500
• Dimension(Long * Breadth * High)：7910*3016*3515mm
• Warranty：1 Year
• Unique Selling Point：Long Lifetime
• Applicable Industries：Construction Works
• Bucket Capacity：2.5-4.5m3
• Hydraulic Valve Brand：Top Brand
• Hydraulic Pump Brand：Top Brand
• Moving Type：Wheel Loader
• Machine Weight：16.9 Tons
• Engine Brand：Wechai
• Trademark：XCMG
• Origin：Jiangsu, China

Parameter Name

Parameter Values (mm)

Notes

Rated working load

5000kg

Standard bucket capacity

2.8 m³

Operating weight

16900kg

Maximum designed speed

Forward/Reverse I Gear

13/18km/h

Forward II Gear

40km/h

Maximum grade ability

28°

Highest Unloading Position

Unloading angel

45°

Unloading height

≥3150mm

Primary bucket cutting-board

Unloading distance

≥1100mm

Primary bucket cutting-board

Bucket digging force

170 kN

Maximum digging depth

36mm

The bucket is placed flat.

Boom lifting time

≤6

Total cycling time

≤10.5s

Minimum turning radius

Outside of bucket

6930mm

Tire center

5950mm

Machine steering angle

±35°

Tire specification

23.5-25

Tire inflation pressure

Front wheel

0.38~0.40MPa

Rear wheel

0.32~0.34MPa
