• Model NO.：300
• Bucket Capacity：1.8m3
• Hydraulic Valve Brand：Top Brand
• Dimension(Long * Breadth * High)：7133*2300*3080 mm
• Warranty：1 Year
• Hydraulic Pump Brand：Top Brand
• Moving Type：Wheel Loader
• Machine Weight：20 Tons
• Engine Brand：Wechai
• Trademark：XCMG
• Origin：Jiangsu, China

ItemParameterRated operating load3000kgBucket capacity1.8m3 standard bucketMachine weight10000kgDumping height2930mmDumping distance1010mmWheelbase2600mmTread1850mmMax. breakout force≥120kNMax. traction≥90kNBoom lifting time5.1sTotal time of three devices11sMin. turning radius (bucket outer)5160mmGradeability28°Tyre Size17.5-25-12PROverall machine dimension LxWxH6970x2482x3025Engine modelYC6B125-T21Related power92/2300 kW/rpm







Summary

Overall Dimension(L*W*H): 7133×2300×3080 mm

Weight:10000 kg

Model Number: LW300FN

Brand Name:XCMG

Place of Origin:China

Certification:CE/ISO9001

Details

Display online time:2018-09-06

weight:10000.000kg

After-sales Service Provided:Engineers available to service machinery overseas

Warranty:12 Months

Condition:NEW

Moving Type:wheel

Rated operating load:3000 kg

Machine weight:10000 kg

Dump clearance at maximum lift:2980 mm

Reach at maximum lift:1410 mm

Wheel base:2600 mm

Tread:1850 mm

Unloading Angle:35°

Caliper Width:1847 mm

Maximum Opening Size:1825 mm

Minimum Rounding Diameter:Φ805 mm

Minimum Ground Clearance:400 mm

Max. breakout force:120 kN

Max. horse power:90 kN

Hydraulic cycle time-raise:≤5.5 s

Total hydraulic cycle time:≤10.3 s

Min. turning radius over tyres:5162 mm

Gradeability:28°

Tyre size:17.5-25

Engine Power:92 kW

Hydraulic Working System Pressure:16 Mpa

Hydraulic Steering System Pressure:14 Mpa

Track Speed:Forward gear:0-10/16/21/35 km/h,Reverse gear:0-14/25 km/h









Advantage

1,The high-efficiency electronic control counter shaft transmission matches perfectly with the engine.

2,The three-stage air filter is designed especially for severe working environment of construction machinery industry.

3,The material and heat treatment for pump shaft connecting spline are improved and the forced lubrication is applied to prolong the life by 20%.

4,With optimized materials and processes, the main reducer and wheel reducer passed the industry's leading reliability life test of >900,000 cycles.

5,The double-pump confluence/distribution technology is applied so that the steering pump preferentially supplies oil to the steering system.
