• Model NO.：GR215A
• Warranty：1 Year
• After-Sales Service Provided：Overseas Service Center Available
• Rated Power/Speed：160kw,2200rpm
• Engine Brand：Top Brand
• Forward Speed(Km/H)：38
• Reverse Speed(Km/H)：23
• Transport Package：Comply with Export Packaging Requirements
• Trademark：XCMG
• Origin：Jiangsu, China

Basic specificationEngine modelQSB6.7/6CTA8.3Rated power/speed164kW/2200rpm  160kW/2200rpmDimension(LxWxH)9180×2625×3470mmOperating weight(Standard)16100kgPerformance specificationTravelling speed ,forward5,8,11,19,23,38 km/hTravelling speed ,reverse5,11,23 km/hTractive force(f=0.75)115.3KNMax. gradeability36%Tire inflation pressure260 kPaWorking hydraulic pressure16 MPaTransmission pressure1.3~1.8MPaMax. steering angle of front wheels±50°Max. lean angle of front wheels±17°Max. oscillation angle of front axle±15°Max. oscillation angle of balance box15Frame articulation angle±27°Min. turning radius using articulation7.3mBiadeMaximum lift above ground450mmMaximum depth of cutting500mmMaximum blade position angle90°Blade cutting angle28°-70°Circle reversing rotation360°Moldboard width ×height4270×610mm
